HTA579 (279) Series Of Fuel Injection Pump Test Bench
Description:
◊ Speed down value is smaller and Output torque larger when Host Frequency Control
◊ With over-voltage, overload, short circuit protection function
◊ High accuracy, low noise, easy to operate
◊ Through the industrial computer to control
◊ Has the speed preset and oil temperature constant temperature control
◊ Rotary speed, counting, temperature, air pressure, rack travel, advance angle digital display
◊ Built-in air source
◊ Data query and print function(Optional)
Functions:
◊ Test each cylinder's delivery at various rotation speeds
◊ Static checking each cylinder's injection timing
◊ Check the mechanical governor
◊ Dispensing pump electromagnetic valve testing
◊ Check the pneumatic governor and booster compensator performance
◊ Measuring the distribution of the pump back to the oil quantity
◊ Advance angle detection function(Optional)
◊ Injection pump seal test
Technical parameters:
Speed range : 0-4000rpm
Measuring cup: 45ml,150ml ……(Optional)
Fuel tank capacity: 60L
Accuracy of the test oil filtration: 5μ
Supply pump pressure: High pressure: 0-4 Mpa Low pressure:0-0.4Mpa
Pressure: 0-0.3Mpa
Center height: 125mm
Electricity: 380V/50Hz, 3 phase or 220V/60 Hz, 3 phase
Output power: 5.5Kw,7.5Kw,11Kw,15Kw...(optional)
Physical size: 2100*1000*1500mm
Net Weight: 850Kg
Company Show
1.About us
Taian HD Power Testing Control Equipment Co.,Ltd is a professional enterprise of design,manufacture and production of internal combustion engine test bench .Scientific research and development, manufacturing, sales of accessories, and strive to build China's first brand of engine testing equipment.
2. Why Choose Us
- Top technology of mould r&d, manufacturing, die steel, heat treatment
- Experienced professional engineers
- Advanced equipment
3. Certifications
