HTS279 Common Rail Tester for Fuel Injection Pump Test Bench

HTS279 Common Rail Tester for Fuel Injection Pump Test Bench thumbnail-1
HTS279 Common Rail Tester for Fuel Injection Pump Test Bench photo-1
US$ 9,000 - 10,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
HD
Model Number:
HTS279
Contact Supplier Request Quote Chat Now
Taian HD Power Testing Control Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name HD
Model Number HTS279
Power Electronic
Usage Auto Testing Machine

Specifications

Frequency :50/60Hz
Heater power:2KW
Speed range :0-4000rpm/min
Voltage:380/220V/3 phase

FUNCTIONS:

1 Test each cylinder's delivery at various rotation speeds

2 Static check each cylinder fuel supply time

3 Check the mechanical governor performance

4 Distribution pump electromagnetic valve test

5 Check the pneumatic governor and booster compensator  performance

6 Measuring distribution pump oil return oil quantity

7 Advance angle detection function(Optional)

8 Injection pump sealing tests

 13 Checking of the sealing of injection pump body.





Technical parameters:

Speed range 0-4000rpm
Measuring cup 45ml,150ml,260ml,360ml,900ml(Optional)
Fuel tank capacity 60L
Accuracy of the test oil filtration 3μ
Supply pump pressure High pressure: 0-4 Mpa  Low pressure:0-0.4Mpa
Pressure 0-0.3Mpa
Center height 125mm
Electricity  380V, 50Hz, 3 phase or 220V, 60 Hz, 3 phase
  Output power 22Kw
Physical size 2100*750*1500mm
  Net Weight 1200Kg


HTS279 Common Rail Tester for Fuel Injection Pump Test Bench

We do our best to provide you with the products of high quality and reasonable price, welcome to contact with us!
For more detail ,please feel free to contact us ,we will try my best to service you.



Contect: vivien
Tel:0086-0538-8530053
Mobile phone: 8613563448723
Skype:vivien-haideck
