Environment friendly WBZ300A Stabilize soil cement mixing plant,stabilized soil mixing plant China for sale with CE approved

Features:

1. Adopting double horizontal shaft continuous mixer;

2. With the electronic scale to measure;

3. Equipped with industrial computer for automatic control and it can be operated manually or automatically;

4. The modular structure facilities the installation of transportation;

5. The batching plant is equipped with electronic belt scale and electronic screw scale;

6. The water supply system adopts turbine flow transducer;

7. Can realize the containerized transport.

Advantages:

1. 30 years OEM experience.

2. High quality and best price

3. Professional suggestions for equipment needs.

4. High reliability

5. Easy operation

We guarantee:

1.Engineers overseas for installation, debugging, operators trainning;

2.Warranty: The warranty period shall be 12 months

3.Providing documents needed, like certificate of origin, commercial invoice.

4.Spare parts supply freely;

5.Maintanence:

A. train your operator to operate correctly;

B. send you operation manual to help you operate machine properly and solve common problem

C. Call us at any time if you have problems

D. we will send engineers to your site to solve problems, if needed.

Installation of stabilized soil mixing plant

1,Installation

Installation site should be plain and wellgrounded. The pithead should be higher than ground to prevent the water inflow.

Lift the mixer with lifting device, and install four supporting legs, connecting angle, inclined strut, ladder and the downward track. Then place the mixer in the appropriate place of the pit.

2,Inspection and preparation before test run:

Check if the connection of the motor and electric element is steady.

Check the connecting bolts between two parts (especially the moving parts) and ensure they are firm

Check if there are sundries stuck in mixing canister and track rack.

3,No-load test run

Start mixing motor. At the same time, the running direction of two mixing shafts should be same with indicating direction of the signs . If there is any difference, change the power connection.

4,Over-load test run

Shut down the discharge door and lift the hopper after feeding. Ensure that the hopper can run steadily and stop on the track freely. If there is slipping, you should put the hopper into the pit bottom then adjust the big nut in brake motor.

 Attentions:

When construction on cement stabilized soil ,you should obey the following requirements:

1) The clod must be smashed as much as possible, and the diameter should not be more than 15mm.

2) The batching proportion should be accurate.

3) The cement should be paved evenly during the road-mixing construction.

4) Watering and mixing should be well-proportioned.

5) The base thickness and elevation should be controlled strictly and the camber slope should be consistent with the surface.

6) When the mixture is at or slightly larger than the optimum water content (it can be 1%-2% larger on hot days ), compact until it reaches the lowest compaction degree confirmed by heavy compaction experiment.
