DTY VR8720 4 Channel Live Viewing /monitoring DVR With Dual sd Card of 128GB

Dty (Shenzhen) Industrial Co., Ltd.

US$ 89 - 139 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

DTY

Model Number:

VR8720

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name DTY

Model Number VR8720

Model: VR8720 (Basic model)

VR8720 Series:

Basic model	VR8720	4ch h.264 sd card mobile dvr
Optional functions	GPS	Record the coordinates and locations
	Wi-Fi	Wireless network
	3G	3G remote view and management

Features

1. Metal shell and Shock-resistant design;

2. Immediately gets into “Record Mode” once turned on;

3. Supports Manual Record, Alarm record and Scheduled Recor

4. Video resolution D1/HD1/CIF/QCIF selectable for each channel; Frame rate 1fps-25fps in PAL or 1fps-30fps in NTSC for each channel.

5. Supports 4 CH “Video & Audio” recording at the same time;

6. Video files can be saved onto SD card up to 64G; dual SD card supported;

7. with user password to keep the data safe;

8. Supports 4 alarm input and 2 alarm output;

9. Video file can be backed up in H.264 format or AVI; and can be played with normal Video player or customized player on PC;

10. Power-off delay to guarantee the DVR would shut down normally to keep recorded files safe when an emergency occurs;

11. Easy operation; supports mouse, keyboard and IR remote control;

12. Supports GPS(optional), WIFI (optional), and 3G (optional);

13. Can work with power supply ranging from DC 8V to DC 36V;

14. 10M/100M Ethernet communication interfaces.

Specifications:

Work Power	DC8V-DC36V
Work Temperature	-10C to +50C
Work Humidity	15%-80%
Supported Memory	Dual SD Cards up to 64 GB
Compression Format	H.264
Video Format	H.264 or AVI
Record Mode	Motion detect/ Manual Record/ Scheduled Record
Video Resolution	D1/HD1/CIF/QCIF for each Channel
Frame Rate	1-25fps (PAL) or 1-30fps (NTSC) for each channel;
Record Signal	4 Channels Video & Audio
TV Standard	PAL and NTSC
File Overwrite	Optional
Compatible camera	Common CMOS or CCD Camera
Alarm in/out	4 Channels inputs; 1 Channel output
USB Port	USB 2.0x2
Mouse / IR Remote	Supported
Menu Language	Multiple Language Options
Dimension	138mm (L) x 112mm (W) x 38mm (H)
Weight	0.845kg
