Mobile cement mixing station factory price
YHZS35 Mobile concrete mixing station is material storage materials, weighing, conveying, mixing, unloading and automatic control system as a whole to focus on concrete production equipment a trailer unit, it fixed all automatic mixing station course of action, operation, maintenance and repair are identical, along with mobile and flexible, quick and easy disassembly, easy to store management and other unique features, the construction project is moving public railways, bridges, ports, utilities and other Best GRF machine type. The biggest bright spot, is easy to install, easy to move, pull away, a stop that is used, and stirred excellent performance, accurate and stable measurement system.
Parameter Model | HZS25 | HZS35 | HZS50 | HZS60 | HZS75 | HZS90 |
(m³/h) Max productivity | 25 | 35 | 50 | 60 | 75 | 90 |
Mixer type | JS500 | JS750 | JS1000 | JS1000 | JS1500A | JS1500B |
batching machine type | PLD800 | PLD1200 | PLD1600 | PLD1600 | PLD2400 | PLD2400 |
(mm)Unloading height | 3800/4000(mm) | 3800(mm) | 3800(mm) | 3800(mm)/4100 | 4100(mm) | 4100(mm)/4200 |
(s)/ cycle time | 72 | 72 | 72 | 72/60 | 72 | 72 |
(L)feeding/discharge capacity | 800/500 | 1200/750 | 1600/100 | 1600/1000 | 2400/1500 | 2400/1500 |
aggregate number | 4 | 4 | 4 | 4 | 4 | 4 |
max aggregate size | ≤40/50mm | ≤40/50mm | ≤60/80mm | ≤60/80mm | ≤60/80mm | ≤60/80mm |
aggregate weighing range | 0-1500kg | 0-2000kg | 0-2000kg | 0-2000kg | 0-3000kg | 0-3000kg |
weighing range | ±2% | ±2% | ±2% | ±2% | ±2% | ±2% |
cement weighing range | 0-300kg | 0-500kg | 0-800kg | 0-800kg | 0-900kg | 0-900kg |
weighing accuracy | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
water weighing range | 0-200kg | 0-300kg | 0-300kg | 0-300kg | 0-400kg | 0-500kg |
weighing accuracy | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
additive weighing range | 0-50kg | 0-50kg | 0-50kg | 0-50kg | 0-50kg | 0-50kg |
weighing accuracy | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
fly ash weighing range | 0-200kg | 0-500kg | 0-500kg | 0-500kg | 0-500kg | 0-500kg |
weighing accuracy | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
We have the following services:
1. installation, debugging, operators trainning;
2. maintanence:
A. when trainning your operators, our engineers will give them advice on how to operate the machines correctly;
B. we will send you the operation manual which can help you operate the machins properly, it can also help you to solve the common problems;
C. Call us at any time if you have problems about our concrete plants;
D. If needed, we will send engineers to your site to solve your problems.
3. providing some documents needed for your customs clearance, like commercial invoice, packing list, certificate of origin etc;
4. lifetime spare parts support.
