Double Glazed Pvc Casement Windows With Low Price

Double Glazed Pvc Casement Windows With Low Price thumbnail-1
Double Glazed Pvc Casement Windows With Low Price thumbnail-2
Double Glazed Pvc Casement Windows With Low Price thumbnail-3
Double Glazed Pvc Casement Windows With Low Price thumbnail-4
Double Glazed Pvc Casement Windows With Low Price thumbnail-5
Double Glazed Pvc Casement Windows With Low Price thumbnail-6
Double Glazed Pvc Casement Windows With Low Price photo-1
Double Glazed Pvc Casement Windows With Low Price photo-2
Double Glazed Pvc Casement Windows With Low Price photo-3
Double Glazed Pvc Casement Windows With Low Price photo-4
Double Glazed Pvc Casement Windows With Low Price photo-5
Double Glazed Pvc Casement Windows With Low Price photo-6
US$ 40 - 160 MOQ: 2 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Wei Bo
Model Number:
WB-60
Contact Supplier Request Quote Chat Now
Foshan Wei Bo PVC Windows & Doors Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
huangpu
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Wei Bo
Model Number WB-60
Frame Material Plastic
Open Style Swing
Type Casement Windows
Opening Pattern Horizontal



double glazed pvc casement windows







Detailed description





famous profile

VEKA,LG CONCH

Window style

European style; American style

Opening style

Sliding, casement, turn-tilt, tilt-sliding, single-hung, double-hung, etc.

Specification

(size, color,etc.)

Different countries have different demands for it; Special shaped windows also can produce. You can design the windows by yourself.

PVC/UPVC profile

LG / Conch / Shide

Glass

Single, double, tripled glass; double glass with grills.

Low-E glass, Tempered glass, floated glass, reflective glass, OBS glass, etc.

Thickness: 4mm, 5mm,6mm,8mm; Space: 6mm,9mm,12mm,16mm, etc.

Reinforcement steel

U form galvanized steel; 1.2mm, 1.5mm, 2.0mm, 2.5mm

Seal

Rubber sealing strip, black or grey color

Hardware

High quality Chinese hardware,Chugn, Guoqiang (Multi-point lock and handle) , G-U or ROTO also can be used

Mosquito meshes

Metal and nylon material



Tech Data Shown Below



Acoustical insulation

36 Db

K-value of window

1. 80 w/ m2. K

Wind resistance

6000 Pa

Air permeability

0. 1 m 3 /h. M

Watertightness

500 Pa



Payment term & load quantity



Payment

T/T, L/C, Western Union

Lead day

15-25 days vary by order quantity

20ft

200pcs for window with normal size(1.2mx1.2m)

90pcs for Doors with normal size(1.8mx2.2m)

40ft

420pcs for window with normal size(1.2mx1.2m)

200pcs for Doors with normal size(1.8mx2.2m)

40HQ

530pcs for window with normal size(1.2mx1.2m)

250pcs for Doors with normal size(1.8mx2.2m)




double glazed pvc casement windows with low price    double glazed pvc casement windows with low price

Profile

Welding

double glazed pvc casement windows with low price

Hardware

double glazed pvc casement windows with low price



Glass

double glazed pvc casement windows with low price



Workshop



double glazed pvc casement windows with low price



Packing



Certification(LG brand profile)

double glazed pvc casement windows with low price



double glazed pvc casement windows with low price

Our company's products

double glazed pvc casement windows with low price



double glazed pvc casement windows with low price

  double glazed pvc casement windows with low price

FAQ



Q1: Are there any problems with the glass inside? Having steam or going foggy? As
       this will be a real problem .

A: Usually, we use 5mm+6A+5mm double glass, you can take easy. Our double glass is made
     professionally, no steam or going foggy between the double glass.

Q2: All these doors and windows come with frames to mount on walls?

A: Yes, all the doors & windows include frames. Installing the windows and doors on wall is OK.

Q3: The glass is broken with no reason, I’m afraid the rest will be broken.

A: The glass would be broken only because suffering from the impact force, but it won’t break itself.

Q4: Can i use 6mm single glass instead of 5mm double glass?

A: It is better to use 5mm double glass, because :
     A )Sliding door looks ugly with single glass. There is a wide space for glass, if you use
          single glass, we will fill so much silicon in it.
     B) 5mm double glass is safer than 6mm single glass.
     C ) 5mm double glass is more soundproof than 6mm single glass.

Q5: Can you use rubber instead of glass silicon?

A: Yes, but it just can be one side, the other side has to be glass silicon. Because it is not
     strong enough to use double rubber. And it is easier to fall off than the glass silicon.

Q6: What is the difference between the 90 degree and 45 degree connecting?

A: There are 90 degree and 45 degree corner connecting. 90 degree window is connected by
     screw, and we assemble the 45 degree window by corner brace. The 45 degree corner
     connecting window is new style, which is easy to overhaul.

Q7: Do you know what is U-value?

A: Yes, it simply means that every degree of temperature difference between a hotter air
     space and a colder air space, the heat energy will transfer per sq.m to the colder air space.
     For example, let say your house has a ceiling area of 100sqm, the difference in temp is
     30deg, and the amount of watts you pay for consume is 6000w. Then the U-value is
     6000w/100m 2 30k=2w/(m 2k).

Q8: What type of fly screen you could supply?

A: We have three styles of fly screen. One is roller style for casement window ,one is sliding
     style for sliding window and door, and the last one is folding style for casement door.
     Besides, the fly screen is made of 3 different materials, namely nylon, steel and Kingkong net.

Q9: PVC and aluminum, which is better?

A: It’s hard to simply say one is better. Each one has its advantages. PVC is good at
     insulation and more economic. Aluminum is better in hardness and security.

Q10: What kinds of packing do you have?

A: There are three kinds of packing, such as bubble bag, bubble bag + wooden frame,bubble
     bag + wooden case. If full container, we advise to use bubble bag, it can save more space
     and hold more goods in the same container. Usually, the packing is bubble bag + wooden
     frame. The best packing is bubble bag + wooden case, some bulk cargo and some developed
     countries, such as USA, Australia and some countries in Europe,need wooden case packing,
     because their special requirement and wooden case can protect the goods very well.

Q11: How many cubic meters would an order like this when packaged occupy in a
        container?

A: As for the container :
(1) 20 container (20GP) can pack 26 cubic meters.
(2)The 40 foot container (40HQ) can hold 54 cubic meters .So how about your idea ?
     Besides , Do you want to quote CIF or FOB or EXW price ? Please kindly let me know .

Q12: What are your payment terms?

A: Usually, our payment terms is T/T:30% deposit,the balance will be paid before delivery, but
     if you want L/C or west union, we also can accept.



Should    be   interested,please    feel   free   to   E-mail   us.

You   will   receive   our   reply   within   24    hours.
