3cube|6cube|8cube|9cube concrete mixer truck with pump CE certificate
Introduction for Fukuda 4 Cubic meter concrete mixer truck :
The four square small mixer using Foton 1860 Rachael King new row of half cab, Yuchai 130 hp (turbocharged) engines, breathe brake, rear axle 1092, five-speed (145HF) transmission with auxiliary transmission, 8.25 -20 tires, 250 double-beam, warm, with full power transmission PTO or PTO, standard domestic reducer, motor, pump 3 large hydraulic parts, hydraulic parts imports also optional; wear-resistant manganese 5 mm steel production, the use of 6 mm head production.
The entire tank mixer with mechanical automatic welding; water supply system for pressure water systems, simplify the structure, save power, reduce vehicle weight; mixing tank plow-shaped structure, the double helix-shaped fan blades in different cone section using different blades, tank installation angle is small, reducing the height of the vehicle center of gravity, with good stability, reducing the tank than expected residual rate (less than one thousandth); operating system is bi-directional control lever linkage operation, there shafts and connecting rods two operating modes, into and out of the feeding device can be rotated 180 degrees in the horizontal direction, with high-grade car paint spray pattern, primer and paint, a variety of optional high-grade paint, such as the choice of baking rush.
Configuration Parameter for Fukuda 4 Cubic Meter Concrete Mixer Truck | |||
Model |
Fukuda truck |
Overall dimension |
6460×2255×3300(mm) |
Girder |
250(6.5mm+5mm) |
Geometrical volume of tank |
4m³ |
Axle base |
3400mm |
Gear case |
145HF5 Five shift transmission |
Front axle |
3.6T |
rear axle |
9T(1092C) |
Wheel |
8.25-20 |
max speed |
83(km/h) |
Motor |
YC4D130-33 |
Exhaust emissions(ml) |
4214 |
Origin |
Guangxi yuchai machinery co., LTD |
Power(kw) |
96 |
Fuel |
diesel |
spring piece(n) |
10/12+9 |
We have the following services:
1. installation, debugging, operators trainning;
2. maintanence:
A. when trainning your operators, our engineers will give them advice on how to operate the machines correctly;
B. we will send you the operation manual which can help you operate the machins properly, it can also help you to solve the common problems;
C. Call us at any time if you have problems about our concrete plants;
D. If needed, we will send engineers to your site to solve your problems.
3. providing some documents needed for your customs clearance, like commercial invoice, packing list, certificate of origin etc;
4. lifetime spare parts support.
