6cube meter concrete mixer truck price with CE certificate
Fukuda medium concrete mixer truck configurations: using Fukuda Ruiwo ADX2200 row of half cab (European luxury), Yuchai 180 hp (EGR) engine, rear axle 10 t (153 enhanced), breathe brake, Shaanxi tooth eight-speed gearbox, 10.00 -20 nylon tires, 280 * 75 * (8 + 4) width 861 local frame three, move forward, metallic paint, warm, full power PTO, wheelbase: 3900mm. Standard domestic reducer, motor, pump 3 large hydraulic parts, hydraulic parts imports also optional; stirred tank volume of 6 cubic meters, with wear-resistant manganese steel production of 5 mm, 6 mm produced using the head.
Tank entire mechanical automatic welding; pressure water supply system for the water supply system, to simplify the structure, save power, reduce vehicle weight; stirred tank plow-shaped structure, the double helix shaped fan blades, the cone section at different using different blades, , tank installation angle is small, reducing the height of the vehicle center of gravity, good driving stability, reducing the tank than expected residual rate (less than one thousandth); operating system is a two-way linkage operation lever controls, and even has a flexible shaft two lever operation, into and out of the feeding device can be rotated 180 degrees in the horizontal direction, with high-grade car paint spray pattern, primer and paint, all kinds of high-grade paint options, such as the choice of baking rush.
Configuration Parameter for Fukuda 6 Cubic Meter Concrete Mixer Truck | |||
Model |
Fukuda truck |
Overall dimension |
7385×2490×3650(mm) |
Girder |
280*75*(8+4)External Width 861 local three double girder frame |
Geometrical volume of tank |
5-6m³ |
Axle base |
3900mm |
Gear case |
Eight shift transmission |
Power Take-off |
Full power |
rear axle |
10T |
Wheel |
10.00-20 |
orientation |
Turn to drive |
Motor |
YC6J180-33 |
Exhaust emissions(ml) |
6494 |
Origin |
Guangxi yuchai machinery co., LTD |
Power(kw) |
132 |
We have the following services:
1. installation, debugging, operators trainning;
2. maintanence:
A. when trainning your operators, our engineers will give them advice on how to operate the machines correctly;
B. we will send you the operation manual which can help you operate the machins properly, it can also help you to solve the common problems;
C. Call us at any time if you have problems about our concrete plants;
D. If needed, we will send engineers to your site to solve your problems.
3. providing some documents needed for your customs clearance, like commercial invoice, packing list, certificate of origin etc;
4. lifetime spare parts support.
