Digital Video Recorder With D1 Resolution and 2ch Audio and Video Record
Function:
1.Immediately get into “Preview” mode once it is turn on;
2.Support manual record,motion detect record,boot record,pre-record and schedule record;
3.Pre Event record:In manual record setting,DVR starts recording 5 seconds or 10 seconds before the REC
key is pressed in preview mode;Or in motion detection mode,DVR starts recording 5 seconds 10 records before the motion is detected by the camera;
4.Scheduled record:This is timer recording.i.e.In preview mode,DVR will be recording during the pre-set time period;
5.Support recording two channels audio and viedo signal at the same time;
6.Support two channels real time D1 recording;
7.32GB SD card can record continously for 48 hours at QVGA resolution;
8.Date,time and ID can be set on the menu;
9.Support NTSC/PAL TV system signal;
10.Maximum support 32GB SD card,file save mold can be stop when full or loop record;
11.Chinese,English,Portugues lanuguage menu are available, software upgrade is avaliable too;
12.Power off delay to ensure the latest file is well saved;
13.DVR can provide DC12V power to two cameras directly,do not need extral power for cameras;
14.With hi-impact alloy house.Anti-vibration design,all the connectors are anti-shake.
15.By using our especially designed control box,the users can operate the DVR conveniently even though it is placed in a concealed position;
Parameters:
Working Voltage DC 12V(DC 12-24V when power camera)
Working Current ≤0.37 A
Working Temprature –10°C~ 50°C
Output Voltage(for camera) DC12V
Maximum Memory 32GB×2
Recording time(with 32GB×2) About 32 hours
Compression File Format MPEG4
Record Format ASF
Record Switch Continuous record or motion detect
Record mode Motion detect and manual record
Record Quality High/Middle/Low
Video Resolution D1 (720×480)
Frame Rate 30 FPS
Resource of signal 2 CH Audio+2 CH Video
File Storing Mode Overwrite when full or stop when full
Compatible camera Common CMOS & CCD
Dimension 137mm×25mm×105mm
Net weight 290G
Packing List:
One DVR
One Power Cable
One Control Box
One AV Cable
Two AVP Cable
One Remote Control
One manual
Four Anti-vibration Rubber
