Car Sensor With Alarm TL109
Quick Details
Type: GPS Tracker |
Use: Automotive |
Screen Size: No |
|
Function: Vehicle Tracking |
Place of Origin: Guangdong China (Mainland) |
Brand Name: No |
|
Model Number: TL-109 |
Type: vehicle GPS Tracker |
Color: Black |
|
Size: 114*64*25.5mm |
GPS chip: Sirf 3 chip |
GPS accuracy: 5m |
|
Net work: GSM/GPRS |
Frequency Band: 900/1800MHz, 850/900/1800/1900M... |
Certification: CE, RoHS |
|
Talking: Yes |
Web Tracking: Available |
||
Packaging & Delivery
Packaging Detail: |
Dimension:114*64*25.5mm Box:22*16.7*6.4cm,650g/box Carton:47*36.5*34cm, 20boxes/carton,14.5kg/carton |
Delivery Detail: |
3 working days after receipt the payment |
Introduction
Working Based on existing GSM /GPRS network and GPS satellites, vehicle tracking solution is a professional system that consists of high sensitive and reliable car GPS trackers and server tracking software. Not only transmit the longitude and latitude coordinate to your cell phone by SMS, but also transmit the coordinate, vehicle status and alarm information to the designated server by GPRS. By this you can know where the vehicle is, where had it been to, what the status it is. You can also stop the vehicle by cutting off the circuit and fuel. What’s more, it support hand-free phone call between the driver and call center. This solution can be widely used in the vehicle tracking, valuable assets monitoring, fleet management area.
Main Features
Real-time locating
Hand-free phone call
Listen in function
ACC detective
Door detective
Fuel detective
SOS alarm
Geo-fence alarm
Speeding alarm
Low power alarm
Power-lost alarm
Cut off the power/fuel
Customizations are welcome Based on Google map
Support multi-users
Real-time tracking
History replay
Report download
Cut off the power/fuel
Set time zone
SOS alarm
Speeding alarm
Geo-fence alarm
Power-lost alarm
Storage data for one month
Customizations are welcome
Applications
Rental vehicle monitoring and management
Taxi/ ambulance/police car dispatch management
GPS tracking service
Guard against thief system
Specification
Dimension 96mm x 64mm x 25mm
Weight 180g
Network GSM/GPRS
Band 900/1800Mhz
850/900/1800/1900Mhz
GPS chip SIRF3 chip
GPS sensitivity -159dBm
Digital input 9-36V DC
Analog Input 0-15V
Cold start 42 sec.
Warm starts 38 sec.
Hot start 1 sec.
Battery Chargeable 3.7V 870mAh battery
Operation temperature -40°C to +75°C
Humidity 5%--95% non-condensing
