Help CenterCutter Sharpener of Knife Sharpening Tools MR-6025
Related Products
-
Blade & Lathe Tool Grinder MR-M3US$ 746 - 964MOQ: 1 Set -
Lathe Tool Grinding Machine MR-M2NegotiableMOQ: 1 Set
-
Universal Cutter and Tool Grinder MR-600US$ 1,019 - 1,182MOQ: 1 Set
-
Lathe Tool & Blade Grinder MR-M2NegotiableMOQ: 5 Sets
-
Lathe Tool & Blade Re-sharpening Machine MR-M2NegotiableMOQ: 5 Sets
Sharpening scope: In hole, outer annulus, column, trench, taper, end mill, disc cutter, lathe tool, square shape and diamond cutting tool, gear cutting tool and so on.
The working table uses dovetail guide rail or high precision straight line roiling guide rails,good back and forth movement, high stability, steady bed platform, dexterous operation.
Motor can rotate 360° in the horizontal plane, the grinding wheel can be clockwise and anticlockwise rapidly. When grind different kinds of material's cutter, you can turn the grinding wheel, which can add the safety and reduce the time of replacing and dressing the grinding wheel, adding controllability of cutter grinding.
1) Standard accessory can grind lathe tool, end milling cutter, face and side cutters, hobbing cutters, circular paper cutters,etc.
2) Choosing 50E accessory can grind MO-type 4# coning spiral milling cutter, ball cutter, R-shape lathe tool,etc.
3) Choosing 50K accessory can grind MO-type 4# coning or diameter 3-32mm drill bit, screw tap, etc.
4) Choosing 50D accessory can grind MO-type 4# coning spiral milling cutter, etc.
5) Choosing 50J thimble, 50B toolbox and so on.
Technical parameters:
Max. Grinding diameter: 250mm
Inner bore of the grinding work piece: 10-50mm
Grinding length: 340/400mm
lateral feeding distance: 190mm
Workable area: 130×680mm
Elevating Distance of Wheelhead: 160mm
Rotating Angle of Wheelhead: 360°
Grinding wheel: 150×16×32mm
Speed of Grinding Wheel: 2800RPM
Grinding head speed: 4200/8000 RPM
Horse Power and Voltage of Motor: 3/4HP
Power: 1HP
Height of the head holder: 135mm
Taper hole of the main spindle of the head holder: MO-type 4#
Motor voltage: 1GP,110V/220V/380V
Dimension: 730×710×715mm
Net weight / gross weight: 212kg/225kg
THE ACCESSORIES:
