Specifications
Tapper roller bearing bearings models 302041.Material:Chrome steel/Carbon steel
2.Self-owned factory
3.High quality
Tapper roller bearing bearings models 30204
The Description of Tapered Roller Bearing
Tapered roller bearing main bear with radial primarily, the axial union load. Bearing outer ring rolling bearing capacity depends on the way Angle, the greater the carrying capacity of the larger Angle. This type of bearings is bearing separation, according to the bearing of the roller column number into a single, double row and four row circular cone roller bearings. The single row circular cone roller bearing clearance to users in the installation to adjust; Double row and four row circular cone roller bearings clearance has set up a file in the products based on user requirements given, don't need to adjust by the user.
Tapered roller bearings taper inner ring and outer ring have groove, tapered roller are arranged in between. All of the surface of the cone of lines in the projection of bearing the same point axis together. This design make circular cone roller bearings is especially suitable for bear composite (radial and axial) the load. The bearing axial load ability is the contact Angle α of the decision; Larger Angle α, axial load capacity is higher. Angle size by calculating coefficient e to say; E value is, the bigger the contact Angle is, the bigger the axial load bearing of the greater the applicability.
Tapered roller bearings are usually separated model, namely the belt roller and maintains a component of the inner circle ,circle of inner cone components and cone outside (outer) can apart installation.
Tapered roller bearings widely used in automotive, rolling mill, mining, metallurgical, plastic machinery, etc.
Company Introduction:
1.We has been specializing in deep geoove ball bearing for14 years .
2. We have our own registered brand"AXB "
3.We supply OEM service
4.We own ISO9001 international quality system certification.
5. We have stable quality control system.
Package:industial package,single carbon box or customized
Certificate:ISO9001:2000,CE
Delivery Time:within 15-20 days normally or as requested
Payment Terms:T/T 30% in advance,70% before delivery agains
| Bearing numbers | Boundary dimensions | Basic load ratings | Limiting speeds | Weight | ||||||
| mm | N | r/min | kg | |||||||
| d | D | T | B | C | dynamic Cr | static Cor | grease | oil | (approx.) | |
| 30202 | 15 | 35 | 11.75 | 11 | 10 | 14800 | 13200 | 11000 | 15000 | 0.053 |
| 30302 | 42 | 14.25 | 13 | 11 | 23200 | 20800 | 9900 | 13000 | 0.098 | |
| 30203 | 17 | 40 | 13.25 | 12 | 11 | 20500 | 20300 | 9900 | 13000 | 0.080 |
| 32203 | 40 | 17.25 | 16 | 14 | 26000 | 22000 | 9900 | 13000 | 0.108 | |
| 30303 | 47 | 15.25 | 14 | 12 | 28900 | 26300 | 9000 | 12000 | 0.134 | |
| 32303 | 47 | 20.25 | 19 | 16 | 27300 | 28300 | 9900 | 13000 | 0.102 | |
| 32004 | 20 | 42 | 15 | 15 | 12 | 24900 | 27900 | 9500 | 13000 | 0.097 |
| 30204 | 47 | 15.25 | 14 | 12 | 28200 | 28700 | 8800 | 12000 | 0.127 | |
| 32204 | 47 | 19.25 | 18 | 15 | 36500 | 39500 | 8800 | 12000 | 0.160 | |
| 30304 | 52 | 16.25 | 16 | 12 | 35500 | 34000 | 8000 | 11000 | 0.169 | |
| 32304 | 52 | 22.25 | 21 | 18 | 46500 | 48500 | 8000 | 11000 | 0.245 | |
| 33004 | 56 | 16.25 | 15 | 11 | 35000 | 33000 | 8000 | 11000 | 0.174 | |
| 320/22 | 22 | 44 | 15 | 15 | 11.5 | 28000 | 33000 | 9000 | 12000 | 0.108 |
| 302/22 | 50 | 15.25 | 14 | 12 | 26500 | 27100 | 8100 | 11000 | 0.141 | |
| 322/22 | 50 | 19.25 | 18 | 15 | 36800 | 41600 | 8100 | 11000 | 0.172 | |
| 303/22 | 56 | 17.25 | 16 | 14 | 36300 | 36600 | 7700 | 10000 | 0.209 | |
| 323/22 | 56 | 22.25 | 21 | 18 | 44600 | 46500 | 7600 | 10000 | 0.263 | |
| 32005 | 25 | 47 | 15 | 15 | 11.5 | 27800 | 33500 | 7900 | 11000 | 0.114 |
| 33005 | 47 | 17 | 17 | 14 | 31000 | 38000 | 8000 | 11000 | 0.131 | |
| 30205 | 52 | 16.25 | 15 | 12 | 31500 | 34000 | 7300 | 9800 | 0.154 | |
| 32205 | 52 | 19.25 | 18 | 15 | 42000 | 47000 | 7300 | 9800 | 0.154 | |
| 30305 | 62 | 18.25 | 17 | 15 | 48500 | 47500 | 6700 | 8900 | 0.272 | |
| 31305 | 62 | 18.25 | 17 | 13 | 38000 | 40000 | 7500 | 11000 | 0.260 | |
| 32305 | 62 | 25.25 | 24 | 20 | 61500 | 64500 | 6700 | 8900 | 0.381 | |
| 33205 | 52 | 22 | 22 | 18 | 47500 | 57500 | 7300 | 9800 | 0.217 | |
