Specifications
The SL30W offers auto-lubrication in the bucket and arm joints.
Product features
Another small offering in wheel loaders, the SL30W still offers mid-range performance for its size. It has autolubrication
in the bucket and arm joints, and comes with a choice of three engines: Xichai, Weichai Deutz and
Dongfeng Cummins. The sealed glass cabin offers a wide field of vision and a shock absorbing seat for greater
driver comfort and safety.
Type In-line, water-cooled, 4-cylinder, direct injection, turbocharged
Rated power 92/92/97 kW
Rated speed 2200 rpm
Displacement 6.557/6.75/5.9 L
Maximum torque 520/500/560 N·m
Minimum fuel consumption 220/215/- g/kW·h
ENGINE
Overall length: 7043 mm
Overall width: 2484 mm
Overall height: 3235 mm
Gear 1st 2nd 3rd 4th
Forward 0~5.8 km/h 0~10.8 km/h 0~18.4 km/h 0~35.0 km/h
Reverse 0~7.8 km/h 0~27.0 km/h – –
TRAVEL
SPEED
Operating weight 10500 kg
Related loading 3000 kg
Bucket capacity 1.7 m3
Maximum lifting force 96 kN
Static tipping load (full turn) 6000 kg
Dumping height (Extended/Long) 2875（3057/3200） mm
Dumping reach (Extended/Long) 955（906/886） mm
GENERAL
SPECIFICATIONS
DRIVE SYSTEM Four-wheel drive
Gradeability 30°
Maximum traction 95 kN
BRAKE SYSTEM:
Service brakes Air over oil four-wheel dual-loop disc brake system
Parking brake Automatically air-cut brake, disc brake
STEERING
SYSTEM:
Type Articulated type, full-hydraulic power steering
Maximum steering angle 36° each direction
The center of outside tire 5300 mm
The center of outside bucket 6004 mm
TIRES
Type 17.5-25 PR
Pattern level L3
Center distance of tires 1856 mm
Wheel base 2700 mm
AXLES AND FINAL DRIVES
Hydraulic
cycle time
(rated load
in bucket)
Lifting time/ Lifting, dumping and lowering 5.5/9.7 s
SHANTUI: CHINA’S KING OF THE HILL IN BULLDOZERSIS NOW HIGHLY DIVERSIFIEDSince its founding in 1980, the name Shantui has beensynonymous with bulldozers in China. And for good reason: Shantui consistently has held more than a 50% share of market in bulldozers in China, and is now the world’s Number One producer and seller of bulldozers,
all under our own brand name.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: what is the product warranty?
12 month from BL date or 2000 working hours whichever comes first.
