Specifications
1.CR-XZ816 is the professional test bench2.Which is used for testing 6 injectors at a time
3.Which can test injection pump
CR-XZ816 test bench is our latest indepentent researched special device to test the performance of high-pressure common rail injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by high-precision flow meter sensors and displayed on computer screen.All data can be searched, saved, modified and made into database. The database will be updated for free. It adopts BOSCH original common rail pump to provide 0~2000 bar of rail pressure. The rail pressure can be adjusted automatically. it can test common rail injector of BOSCH, SIEMENS, DELPHI, DENSO. Advanced technology, steady performance, precise measurement and convenient operation.
>>>CHARACTERISTIC
1. Controlled by industrial computer in real time, Windows operating system.
2. Oil quantity is measured by sensor and displayed on 19'' tactile LCD screen;
3. Data can be searched, printed and made into database.
4. Database contains more than 400 kinds of injectors data.
5. It is installed BOSCH common rail pump to provide 0~2000 bar of rail pressure.
6. Rail pressure can be tested in real time, it contains the high-pressure protection function
7. Pulse and frequency of the injector drive signal can be adjusted.
8. Injection time can be set.
9. Protection function of short-circuit.
10. Precise measurement, easy operation, low noise.
>>>FUNCTION
1. test injector brands: BOSCH, SIEMENS, DELPHI, DENSO,CATERPILLAR.
2. test 6 piece of injectors at a time.
3. test the pre-injection oil quantity of common rail injector.
4. test the max. oil quantity of common rail injector.
5. test the cranking oil quantity of common rail injector.
6. test the backflow oil quantity of common rail injector.
7. test the average oil quantity of common rail injector.
8. test the seal performance of common rail injector.
9. Data can be searched, printed and made into database.
>>>TECHNICAL PARAMETER
1. Pulse width: 0.1~20ms
2. Continuous injection times: 0~1000
3. Fuel temperature: 40±2 centigrade
4. Rail high pressure: 0~2000 bar
5. Test oil filtered precision: 5μ
6. Input power: 380V/50hz/3phase or 220V/60hz/3phase
7. Rotation speed: 0~3000RPM
8. Overall dimension(CM): 195×80×155
9. Weight:1200KG.
