Help CenterTXT-B Diesel Fuel Injection Pump Test Bench
Related Products
-
CRI-XZ100B Common Rail Injector Test BenchNegotiableMOQ: 1 Set -
CRI-XZS II Common Rail Injector Test BenchUS$ 3,600 - 4,000MOQ: 1 Set
-
GPS916 Diesel Fuel Injection Pump Test BenchUS$ 3,800 - 5,200MOQ: 1 Set
-
PCM-E Diesel Fuel Injection Pump Test BenchNegotiableMOQ: 1 Set
-
12PSB-C Diesel Fuel Injection Pump Test BenchUS$ 3,600 - 4,000MOQ: 1 Set
Specifications
TXT-B Diesel fuel injection pump test bench is in a high quality and a reasonable price.Output power(KW): 7.5/11/15/18.5/22ecTXT-B diesel fuel injection pump test bench
FUNCTIONS
1 Measurement of each cylinder's delivery at any speed.
2 Checking of each cylinder's injection timing with static.
3 Checking of the sealing of injection pump body.
4 Checking of the advance device in dynamics.
5 Checking of the pneumatic governor.
6 Checking of the mechanical governor.
7 Checking of the vacuum capacity of governor.
8 Measurement of the internal pressure of distributor pump body.
9 Measurement of the reflux delivery of distributor pump.
Testing of the 10 electro-magnetic valve of distributor pump.
11 Checking of the transfer pump.
12 Checking of the LDA.
CHARACTERISTIC
1 Typical product.
2 Inverter driver.
3 Adjusting speed by two ways, hand and preset speed. 7-steps speed preset.
4 High output torque, low fall of rotation speed. Adjusting speed quickly.
5 Speed, strokes, advance angle and oil temperature are displayed by digital instruments.
6 With protect function for over and low voltage and short phase.
7 Save electric power.
8 It can test both distributor ( VE ) and in-line pumps.
PARAMETERS
Output power:7.5/11/15/18.5/22/30KW
Electric supply:3phase 380V/50HZor on request
Interaxe height:125mm
Volume of fuel tank:60L
Cylinders:12cyl.
Feeding fuel pressure low0-0.4MPA high0-4MPA
Range of speed:+/-0-4000RPM
Control fuel temperature:40+/-2
DC. supply:12/24V
Output air:-0.05-0.3MPA
