Help CenterRechargeable Wireless PIR Motion Sensor ,alarm Sensor
Related Products
-
Wireless Door Sensor With 433/868 MHZ for OptionalUS$ 2 - 3MOQ: 1 Piece -
Outdoor Siren With Strobe &120dbUS$ 10 - 15MOQ: 1 Piece
-
Outdoor Burglar Alarm Siren &Blue Siren GS-SS02BUS$ 10 - 15MOQ: 1 Piece
-
Wireless Panic Button GS-WEB01,868MHZ,rechargeabledUS$ 2 - 3MOQ: 1 Piece
-
Wireless Outdoor PIR Motion SensorUS$ 1 - 10MOQ: 1 Piece
Specifications
Pir detector manufacturer1,Wireless frequency : 433MHz/868Mhz
2,Detecting distance:8-12m
3,CE
Rechargeable Wireless PIR motion Sensor ,alarm sensor
I. Functions Features:
- Microcomputer intelligent control, stable performance, artistic outlooks design;
- Infrared detection, temperature compensation, energy-saving mode available;
- Movement alarm, weak power alarm, tamper alarm;
- High capacity rechargeable Lithium battery, long service life, with USB charging port;
- Mainly monitor and control indoor stereoscopic spaces, generally set as Motion Zone.
II. Technical Parameters:
- Power Supply: 3.7V/800mAh rechargeable Lithium battery
- Transmitting Distance: ≥ 150 meters (in open air)
- Full loaded battery work time: ≤2 years
- Charging time: ≥ 8 h
- Detecting range: 110° 10m×10m
III. Installation and Usage:
1. Fix the bracket to a proper wall surface or corner. The optimum mounting height is 2~2.4 above the floor.
2. Turn on the power by sliding the power switch (on the back of the PIR) to “ON”, the PIR sensor will flash 30
seconds and then get into normal working status.
3. Fix the PIR sensor to the bracket and adjust it to a proper detecting angle.
4. Detecting Time Jumper setting instructions (should open the shell of the PIR)
1. 5S: Detects every 5 seconds (Recommended for testing)
2. 5MIN: Detects every 5 minutes. (Recommended for normal use to lengthen the battery life)
5. Movement Alarm: Under working status, if the PIR triggered by movement, Working Light flashes 1 time, at the
same time sends detecting alarm signal to the host.
6. Tamper Alarm: Under working status, if the shell of the PIR is opened, Working Light flashes 1 time, at the
same time sends tamper alarm signal to the host.
7. Weak Power Alarm: Under weak power status, if the PIR triggered by movement, Working Light flashes 1 time, at the same time sends detecting alarm signal to the host. And then flashes 3 times and at the same time sends
weak power signal to the host.
Note: The maximum weak power alert is only 2 times for each time the battery almost runs out. So please charge the battery or change new battery to keep it work normally.
8. USB Charging: Option 1---Use USB charging adaptor;
Option 2---Use USB cable to charge by computer.
Send Inquiry to This Supplier
