Specifications
1.Test common rail pump and injector.2.Also can test traditional pump.
3.Displayed by 19" LCD screen
4.Datas can be updated
CRS-300 Multi-functional test bench
Advanced common rail test system mounted on the traditional test bench, multi-use of one machine, can test not only common rail pump& injector but also traditional pump. Excellent quality and stable in performance, is ideal choice for you.
Parameter:
1 .Output power:11KW,15KW
2 .Pressure:0~2000 bar
3 .RPM:0~3500
4. Size: 208*175*80(mm)
5.Weight:1280 kg
Controlled by industrial computer; Windows XP operating system; Displayed by 19” LCD screen. With database can be upgraded.
Common Rail Pump test:
Test BOSCH CP1/CP2/CP3, DELPHI CRSP, DENSO HP0/HP3/HP4, SIEMENS DCP pump and so on.
Drove by original Bosch pump, pressure created 0~2000bar, Measure the feeding and return volume, pump chamber pressure, feeding pressure, check sealing performance, and functions of ZME valve.
Common rail injector test:
Test BOSCH, DENSO, DELPHI, SIEMENS, CATERPILLA injectors.
1. Test up to 6pcs injectors at any one time.
2. Automatic high-pressure cleaning.
3.Test the oil injection and oil return under the circumstance of sealing, pilot injection, idle operation, full load.
4. Create, edit, view, save test plans easily.
