Specifications
ure:0~2000bar2.output power:11kw,15kw,18.5kw
3.weight:1200kg size:195cm*80cm*155cm
dows xp
5.flow sensor
CR-XZ816-2common rail pump&injector test bench can test the diesel pumps and injectors with many applications to BOSCH, DENSO, DELPHI and so on.
Common rail pump test:
Test BOSCH CP1/CP2/CP3, DELPHI CRSP, DENSO HP0/HP3/HP4, SIEMENS DCP pump and so on.
Measure the feeding and return volume, pump chamber pressure, feeding pressure, check sealing performance, and functions of ZME valve.
Output power |
11KW,15KW |
Speed |
0~3000n/min |
Pressure |
0~2000 bar |
Size |
195cm*80cm*155cm |
Weight |
1200kg |
Common rail injector test:
Such as BOSCH, DENSO, DELPHI and so on.
1 Test up to 6pcs injectors at any one time.
2 Automatic high-pressure cleaning to remove the impurities in it
3 With high accuracy import flow sensor, automatic test the oil injection and oil return under the circumstance of sealing, pre-injection, full load, idle operation, and calibrating; closed-loop control.
4Self-learning ability, automatic create new plans by testing new injectors; view, create, edit, save test plans easily
Industrial Human-machine Interface
Windows XP system
Self-learning ability
Automatic Temperature Control
Derived by BOSCH CP3 pump
DRV wave pressure control
Import Flow Sensor
Transparent safety protection
