Help CenterHot Sale Straw Pellet Making Machine
Related Products
Specifications
hot sale straw pellet making machine1.Automatic control
2.Low noise
3.High efficiency
4.Smooth granule
hot sale straw pellet making machine
Product Information
Ring Die Pellet Machine, also called Ring Die Grain Feed Machine, or Ring Die Feed Pelletizer Forming Machine, is one of the feed grain making equipments.
It is a feed processing machinery through pelletizing crushing things(such as corn, bean pulp,crop straw, grass and rice hull).
Finished pellet samples
Working Principle
1.Feeding Methods
A.Mechanical and automatic feeding system;
B.High-speed revolution;
C.Centrifugal distribution into granulating chamber;
D.Distribute materials by scraper.
2.Discharging Methods
The ring die particles machine works in high-speed revolution. Material breakage rate is high.
Main Technical Parameter
Model | Main motor power (kw) | Capacity(t/h) | Feeding motor power(kw) | Tuned motor power(kw) | Circling mold diameter(mm) | Granulating specification(mm) |
SZLH25 | 15/15.8 | 0.5-1.5 | 0.75 | 2.2 | Φ250 | Φ2--8 |
SZLH32 | 37 | 2-5 | 0.75 | 2.2 | Φ320 | Φ2--8 |
SZLH35 | 55 | 2-8 | 0.75 | 2.2 | Φ350 | Φ2--8 |
SZLH40 | 75 | 2-10 | 1.5 | 2.2 | Φ400 | Φ2--8 |
SZLH42 | 110 | 3-12 | 1.5 | 5.5 | Φ420 | Φ2--8 |
SZLH508 | 132/160 | 4-20 | 1.5 | 7.5 | Φ508 | Φ2--8 |
Main Feature
1.High longevity, high quality and smooth particles/granules;
2.Automatic steam adjustment system, and constant modulation temperature;
3.Accurate wheel gear transmission helps the output is 20% higher than normal ones;
4.quality bearings make the machine efficient, stable and low noise;
5.All stainless steel and large strengthened feeding conditioner;
6.High performance permanent magnet device.
Pictures for your reference
Note
Any questions or inquiries are warmly welcomed!
Please feel free to ask me.
