40W Warm/Pure/Cold White LED Panel 62x62
Parameter of led panel 62x62 :
| Name | led panel 62x62 |
| Power | 40w |
| Voltage | AC85-265V |
| Light efficiency | 90-100lm/w |
| CRI | 80 |
| Pf | 0.95(Copy right of suspended led panel) |
| CCT | 2800-3500k,4000-4500k,5500-6500k |
| Led qty | 120pcs |
| Led type | SMD2835 |
| Beam angle | 180° (Copy right ofsuspended led panel) |
| Material | Aluminum alloy and PC |
| Optional PC cover | Forsted |
| Size | 620x620mm |
| Surface temperature | 42℃-45℃ |
| Ambient temperature | -20℃-45℃ |
| Certs | CE ROHS |
| Warrenty | 3years |
| Item No. | Watt(W) | Voltage(V) | LED Q'ty(pcs) | Dim.(mm) |
| JL-PL-3310-N | 10W | AC-86-265V | 40pcs SMD2835 | 300*300 |
| JL-PL-3620-N | 20W | AC85-265V | 50pcs SMD2835 | 600*300 |
| JL-PL-6640-N | 40W | AC85-265V | 100pcs SMD2835 | 600*600 |
| JL-PL-626240-N | 40 | AC85-265V | 96pcs SMD2835 | 620*620 |
| JL-PL-31240-N | 40W | AC85-265V | 100pcs SMD2835 | 3001200 |
| JL-PL-61280-N | 72W | AC85-265V | 200PCS smd2835 | 600*1200 |
Features of led panel 62x62 :
1.High safety: the required voltage, current smaller, less heat, no safety problems can be used for mining and other dangerous places.
2.High efficiency and less consumption :70-80% energy-saving than CFL lamp.
3.Long life span: up to 50,000hours.
4.Reliable and durable: suspended led panel does not contain easily-broken components,such as tungsten filament,glass, etc.
5.Environment-friendly:the wasted materials of suspended led panel can be recycled, with no radial intenerence,no Hg&Pb pollution.
6.Short response time,No flicker,no noise. (Copy right of suspended led panel)
7.We recommend suspended led panel to you not only the best price but also the very good quality we sure that you can`t find same price at this quality level.
Photos of led panel 62x62 :
Warning:
1.Only qualified person should perform suspended led panel installation.
2.Input voltage of suspended led panel is AC86-AC265V, so pls make sure power off when installation to prevent electric shock.
3.When the temperature of suspended led panel is too high,Over-temperature control circuitry activates, Output will be cut off,and the lamp will light off for a few minutes then light again.
Warrenty of led panel 62x62 :
Our company's products(not only suspended led panel) are used in constant current power supply, the whole lamp warranty for three years, one month replacement. (jierlight led light panel)
Remark:The warranty of suspended led panel on the base of right storing way,right installing way,right using way,right maintaining way.During the warranty time,we can choose repairing,replacing parts or replacing the whole products according the detail information.And we'll charge the customers some material fee and labor cost if suspended led panel out of our warranty time.
Trade items of led panel 62x62 :
1.Payment terms: T/T 30% deposit after suspended led panel order confirmed, the balance 70% to be paid before delivery,Or Western Union and Paypal for small amount . (Copy right of led light panel)
2.Delivery time: For sample order:3-5 days; 100~500pcs: 5-6 days,500~1000pcs:7 days
3.Shipping Method :We ship suspended led panel by UPS/DHL/FEDEX/TNT express which takes 3~ 5 days to arrive, or by air which takes about one week to arrive , or by sea which takes about one month to arrive, depending on your actual requirements.
4.Shipping port: shenzhen , China.(Copy right of suspended led panel)
5.Discounts are offered based on order quantities.
Application of led panel 62x62 :
