40W LED Panel Light With DLC 4.0 2x2 LED Drop Ceiling Light Panels

Name: 40W LED Panel Light With DLC 4.0 2x2 LED Drop Ceiling Light Panels
Brand: JIERLIGHT
SKU: 112131503
Availability: InStock

40W LED Panel Light With DLC 4.0 2x2 LED Drop Ceiling Light Panels thumbnail-1

40W LED Panel Light With DLC 4.0 2x2 LED Drop Ceiling Light Panels photo-1

US$ 28 - 29 MOQ: 1 Piece

Key Specifications

Get Latest Price

LED Light Source:

SMD2835

Warranty(Years):

Input Voltage(V):

AC100-277V

Contact Supplier Request Quote Chat Now

Shenzhen Jier Light Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD2835

Warranty(Years) 3

Input Voltage(V) AC100-277V

Lamp Power(W) 40

Lamp Luminous Flux(lm) 4400

Lamp Luminous Efficiency(lm/w) 110

Color Temperature(CCT) Warm White

Working Temperature(℃) -25, 55

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP44

Certification C-tick, CCC, CE, EMC, FCC, LVD, SAA, UL

Place of Origin Guangdong, China

Brand Name JIERLIGHT

Model Number JR22-D40W

40W LED Panel Light with DLC 4.0 2x2 LED Drop Ceiling Light Panels

PARAMETER OF 2x2 LED Drop Ceiling Light Panels:

Name	2x2 LED Drop Ceiling Light Panels
Power	40w
Voltage	AC100-277V
Light efficiency	100-110lm/w
CRI	80
Pf	0.95
CCT	2700-3500k,4000-4500k,5000-5500k
Led qty	192pcs
Led type	SMD2835
Beam angle	180°
Material	Aluminum alloy and PC
Optional PC cover	Forsted
Size	603*603mm
Surface temperature	42℃-45℃
Ambient temperature	-20℃-45℃

FEATURES OF 2x2 LED Drop Ceiling Light Panels:

1.High safety: the required voltage, current smaller, less heat, no safety problems can be used for mining and other dangerous places.

2.High efficiency and less consumption :70-80% energy-saving than CFL lamp.

3.Long life span: up to 50,000hours

4.Reliable and durable: panel light led lamp does not contain easily-broken components,such as tungsten filament,glass, etc.

5.Environment-friendly:the wasted materials of panel light led lamp can be recycled, with no radial intenerence,no Hg&Pb pollution.

6.Short response time,No flicker,no noise.

7.We recommend panel light led lamp to you not only the best price but also the very good quality we sure that you can`t find same price at this quality level.

PRODUCT PHOTO OF 2x2 LED Drop Ceiling Light Panels:

INSTALLATION OF 2x2 LED Drop Ceiling Light Panels:

Warning:

1.Only qualified person should perform panel light led lamp installation

2.Input voltage of panel light led lamp is AC86-AC265V, so pls make sure power off when installation to prevent electric shock.

3. When the temperature of panel light led lamp is too high,Over-temperature control circuitry activates, Output will be cut off,and the lamp will light off for a few minutes then light again.

WARRENTY OF 2x2 LED Drop Ceiling Light Panels:

Our company's products(not only panel light led lamp ) are used in constant current power supply, the whole lamp warranty for three years, one month replacement

Remark:The warranty of panel light led lamp on the base of right storing way,right installing way,right using way,right maintaining way.During the warranty time,we can choose repairing,replacing parts or replacing the whole products according the detail information.And we'll charge the customers some material fee and labor cost if panel light led lamp out of our warranty time. (

TRADE TERMS OF 2x2 LED Drop Ceiling Light Panels:

1.Payment terms: T/T 30% deposit after order confirmed, the balance 70% to be paid before delivery. Or Western Union and Paypal for small amount .

2.Delivery time: For sample orde:3-5 days; for 100~500pcs: 5-6 days, 500~1000pcs:7 days

3.Shipping Method :We ship panel light led lamp by UPS/DHL/FEDEX/TNT express which takes 3~ 5 days to arrive, or by air which takes about one week to arrive , or by sea which takes about one month to arrive, depending on your actual requirements. .

4.Shipping port: shenzhen , China

5.Discounts are offered based on order quantities.

APPLICATION OF 2x2 LED Drop Ceiling Light Panels:

If you want to know more about 2x2 led drop ceiling light panels, ask me directly pls!
