Home > Lights & Lighting > LED Interior Lighting > LED Panel Light > 3-24W Square and Round 8 Inch Round LED Panel Light

3-24W Square and Round 8 Inch Round LED Panel Light

Name: 3-24W Square and Round 8 Inch Round LED Panel Light
Brand: JIERLIGHT
SKU: 112131349
Availability: InStock

3-24W Square and Round 8 Inch Round LED Panel Light thumbnail-1

3-24W Square and Round 8 Inch Round LED Panel Light thumbnail-2

3-24W Square and Round 8 Inch Round LED Panel Light photo-1

3-24W Square and Round 8 Inch Round LED Panel Light photo-2

US$ 4.9 - 5.2 MOQ: 1 Piece

Key Specifications

Get Latest Price

LED Light Source:

SMD2835

Warranty(Years):

Input Voltage(V):

AC85-265V

Contact Supplier Request Quote Chat Now

Shenzhen Jier Light Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

LED Light Source SMD2835

Warranty(Years) 3

Input Voltage(V) AC85-265V

Lamp Power(W) 18

Lamp Luminous Flux(lm) 1600

Lamp Luminous Efficiency(lm/w) 80

Color Temperature(CCT) Other, 2800-6500K

Working Temperature(℃) -25, 55

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP44

Certification C-tick, CCC, CE, EMC, FCC, LVD, SAA, UL

Place of Origin Guangdong, China

Brand Name JIERLIGHT

Model Number JL-RP-18W

3-24W Square and Round 8 inch Round LED Panel Light

PARAMETER OF 8 inch Round LED Panel Light :

Name	8 inch Round LED Panel Light
Power	18w
Voltage	AC85-265V
Light efficiency	90lm/w
CRI	85
Pf	0.95
CCT	2800-3500k,4000-4500k,5500-6500k
Led qty	90pcs
Led type	SMD2835
Beam angle	110°
Material	Aluminum alloy and PC
Optional PC cover	Forsted
Size	Ø22012mm (6inch) , Ø20512mm(cutout)
Surface temperature	42℃-45℃
Ambient temperature	-20℃-45℃

FEATURES OF 8 inch Round LED Panel Light :

1.High safety: the required voltage, current smaller, less heat, no safety problems can be used for mining and other dangerous places.

2.High efficiency and less consumption :70-80% energy-saving than CFL lamp.

3.Long life span: up to 50,000hours

4.Reliable and durable: led ceiling fan with light does not contain easily-broken components,such as tungsten filament,glass, etc.

5.Environment-friendly:the wasted materials of led ceiling light can be recycled, with no radial intenerence,no Hg&Pb pollution.

6.Short response time,No flicker,no noise.

7.We recommend led ceiling fan with light to you not only the best price but also the very good quality we sure that you can`t find same price at this quality level.

PRODUCT PHOTO OF 8 inch Round LED Panel Light :

INSTALLATION OF 8 inch Round LED Panel Light:

Warning:

1.Only qualified person should perform led ceiling fan with light installation

2.Input voltage of led ceiling fan with light is AC86-AC265V, so pls make sure power off when installation to prevent electric shock.

3. When the temperature of light is too high,Over-temperature control circuitry activates, Output will be cut off,and the lamp will light off for a few minutes then light again.

OTHER ROUND LED PANEL:

CODE	LED QTY	POWER	CCT	lm/W	SIZE	PF	IN.VOL	CRI
JL-RP-3W	15PCS	3W	2800-6500K	180LM	ø9512mm , ø8512mm(cutout)	≥0.90	AC85-265V	>80
JL-RP-4W	20PCS	4W	3822-6500K	240LM	ø10512mm , ø9512mm(cutout)
JL-RP-6W	30 PCS	6w	2800-6500K	400LM	ø12012mm , ø10512mm(cutout)
JL-RP-9W	45 PCS	9w	2800-6500K	6200LM	Ø14512mm , Ø13012mm (cutout)
JL-RP-12W	60 PCS	12W	2800-6500K	880lm	Ø17012mm , Ø15512mm (cutout)
JL-RP-15W	75PCS	15W	2800-6500K	1150LM	ø20012mm , ø18512mm(cutout)
JL-RP-18W	90 PCS	18w	2800-6500K	1600LM	Ø22012mm, Ø20512mm(cutout)
JL-RP-24W	120PCS	24W	2800-6500K	21600LM	ø30012mm , ø28012mm(cutout)

WARRENTY OF 8 inch Round LED Panel Light:

Our company's products(not only led ceiling fan with light ) are used in constant current power supply, the whole lamp warranty for three years, one month replacement

Remark:The warranty of led ceiling fan with light on the base of right storing way,right installing way,right using way,right maintaining way.During the warranty time,we can choose repairing,replacing parts or replacing the whole products according the detail information.And we'll charge the customers some material fee and labor cost if led ceiling fan with light out of our warranty time. (

TRADE TERMS OF 8 inch Round LED Panel Light:

1.Payment terms: T/T 30% deposit after order confirmed, the balance 70% to be paid before delivery. Or Western Union and Paypal for small amount .

2.Delivery time: For sample orde:3-5 days; for 100~500pcs: 5-6 days, 500~1000pcs:7 days

3.Shipping Method :We ship led ceiling fan with light by UPS/DHL/FEDEX/TNT express which takes 3~ 5 days to arrive, or by air which takes about one week to arrive , or by sea which takes about one month to arrive, depending on your actual requirements. .

4.Shipping port: shenzhen , China

5.Discounts are offered based on order quantities of led ceiling light.

APPLICATION OF 8 inch Round LED Panel Light:
