Flat thrust needle roller bearing AXK1024

Tube & Box Marking:1. Lasermarking on outerface of outerring like Brand, 2.Print Brand on Rubber/Metal shield

Specifications

thrust needle roller bearing AXK1024:
1.Single direction axial
2.high loading capacity
3.High stiffness
4Wide application

  Flat thrust needle roller bearing AXK1024

Axk Needle Roller Bearing



These bearings can be used without thrust washers when the faces of adjacent machine components can serve as raceways, allowing the machine to be even more compact. These bearings provide a high degree of stiffness and are most suitable where high accuracy is required at high speeds and under fluctuating heavy loads, such as machine tools and high-pressure pumps.



Product details



Shaft Diameter	Bearing Designation		Boundary Dimensions
	Axial Needl Roller and Cage Asserbliies	Shaft Loc. Washer	dw	dg	Dw	Dg	dr	h	s	a	rs min
mm			mm
4	AXK0414TN		4	-	-	14	2
5	AXK0515TN		5	-	-	15	2
6	AXK0619TN		6	-	-	19	2
8	AXK0821TN		8	-	-	21	2
10	AXK1024	AS1024	10	-	-	24	2	2.75	1	0.5	-
Basic load rating:	C: 9200N	Co: 25500N
