Help Center17 Inch Electronic Chart System (ECS)
Related Products
-
Professional Reflective Compass for Ship Use Magnetic CompassUS$ 3,200 - 3,250MOQ: 1 Set -
Bearing Repeater Compass With Digital DisplayUS$ 810 - 820MOQ: 1 Set
-
Professional Reflector Compass for Ship Use Magnetic CompassUS$ 2,900 - 3,000MOQ: 1 Piece
-
Continuous-wave Navigation Marine Radar For BoatUS$ 2,900 - 2,950MOQ: 1 Set
-
Marine Aneroid Barometer With Plastic ShellUS$ 95.00 - 95.00MOQ: 100 Pieces
Brief introduction:
ECS is an innovative ship navigation product that supports S-57 and S-63 data format and S-52 display standard and integrates many systems such as electronic chart display and information system, consolidated notam system and safety system. The product meets IHO S-52, IHO S-57, IHO S-63 and IEC60945, as well as Function, Performance and Test Requirements of Electronic Chart System (ECS) (Interim) , and has obtained the model approval from China Classification Society (CCS) (certificate number: CQ11T00007).
Function:
the system can access AIS, GPS, heading and other sensors. It has the functions of chart display and update, route design, course record, sailing monitoring and alarm, etc. With this system, a ship can sail safer than before. It can reduce the occurrence of errors and accidents, and greatly help you avoid a collision between ships or administer the ships or harbors.
Feature:
The system is a kind of integrated equipment that supports S-57 and S-63 data format and S-52 display standard. The operation is simple and visual.
Specification:
Chart format:IHO S-57,S-63
Data interface:8 serial ports: six RS422 serial ports and two RS232 serial ports; 4 USBs, 1 audio interface, 1 network interface of 10M/100M
Operating voltage:DC 6V~32V
Power consumption:≤40W
Display resolution: 1280×1024
Operating temperature: -15℃~+55℃
Harmonic and clutter suppression: ≤-70dBc
Operating temperature: -20℃~+60℃
Electromagnetic compatibility: Compliant with IEC60945
Vibration: Compliant with IEC60945
Dimensions: 408mm×439mm×170mm
Weight: ≤11kg
