TCT Saw Blade for cutting laminated panels
Specifications
1.Size: 200MM-400MM
2. Body material: No. 50 Steel or the other
3. Standard: JIS, TUV, ISO9001 & MPA certificate
4. fast cutting ability and good heat dissipation
5. long working life, high precision and low noise
6. Package: color box, double blister card, skin packing, white box etc.
What the specification of our saw blade ? |
Product Name |
TCT Saw Blade for cutting laminated panels |
Body material |
No. 50 Steel, 65Mn, SKS-5 or others |
Outer Diameter |
mm |
Body thickness |
2.2mm/2.5mm |
Bore Size |
30mm |
Body hardness |
HRC 40 - 42 |
Teeth No. |
48T—120T |
Teeth type |
ATB/TCG /Flat teeth |
Tip material |
Common / YG8 /Zhuzhou tip or the other |
Finishing |
Polishing, Electroplating, Cataphoresis |
Surface Finish |
Powder Painting ( Black/ Gray) , Sand Blasted or color painting |
Application |
Suitable for wood, plywood, veneer, hardboard, fiberboard, laminated panels, chipboards, MDF etc. |
Our available saw blade Size |
TCT saw blade to cut laminated panels | |||||
Diameter(mm) |
Inch |
Width |
Thick |
Hole |
Teeth |
200 |
8" |
3.2 |
2.2 |
30 |
48 |
250 |
10" |
3.2 |
2.2 |
30 |
60 |
300 |
12" |
3.2 |
2.2 |
30 |
60 |
350 |
14" |
3.5 |
2.5 |
30 |
72 |
400 |
16" |
3.5 |
2.5 |
30 |
80 |
250 |
10" |
3.2 |
2.2 |
30 |
80 |
300 |
12" |
3.2 |
2.2 |
30 |
72 |
300 |
12" |
3.2 |
2.2 |
30 |
96 |
350 |
14" |
3.5 |
2.5 |
30 |
84 |
350 |
14" |
3.5 |
2.5 |
30 |
96 |
350 |
14" |
3.5 |
2.5 |
30 |
108 |
400 |
16" |
3.5 |
2.5 |
30 |
96 |
400 |
16" |
3.5 |
2.5 |
30 |
120 |
Hints and Tips |
1. Keep wearing eye and face protection while you are doing cutting works!
2. Do not wear loose clothes, jewelry and gloves!
3. Never fit or change the saw blades while the tools are working or the plug is still connecting!
4. Please remember use the right size of saw blade with suitable power tools!
5. This kind carbide saw blade is designed for cutting wood, plywood, veneer, hardboard,
fiberboard,laminated panels, chipboards, MDF etc.
Do not use it for cutting concrete, stone, metal or other similar material!
Payment and delivery terms |
MOQ |
1000PCS |
Lead Time |
First order: 30~45days; Repeat orders: 30days receiving your deposit |
Payment Terms |
T/T, Western Uion, L/C, Paypal |
Package |
color box, double blister card, skin packing, white box etc |
Loading Port |
Shanghai ,Ningbo or other Chinese Port |
Inquiry response: Your inquiries will be replied in 12 hours.
Sample Policy: Honored to offer free sample to our customers
Delivery time: 30-35days for 40HQ once receiving the deposit
Payment &Delivery:T/T, Cash, L/C.
OEM and ODM are welcomed.
Splendid is a professional household electrical appliances and power tools manufacturer. Our
location is in the Dagang new district, Zhenjiang city, Jiangsu province, which district as a
transportation junction of railway, waterway, highway ,etc.
Main products of our factory are:
1.heating element, water heater, heating resistor, electric boiling heater;
2.wire, extension wire, power plug cable,;
3.electrical appliances, hardware tools, drill bit, saw blade;
Our company also self-supporting and could agent import and export all kinds of goods and
technology business. And is willing to design and development various electric heat equipments,
power plug cables, and hardware tools for domestic and foreign customers.
Products approved ISO9001:2008, CQC, CE and Lvd certification. We have exported to more
than 40 countries and regions like America, Mexico, Brazil, Argentina, Britain, Russia, Japan, Korea, India, South Africa and so on. We also became the supplier for chain hypermarket like
WAL-MART, CARREGOUR, etc.
Our team obedience to the tenet of “To the quality strives for the survival, To the benefit strives
for the development ”.We sincerely welcome you to establish long-term partnership with us, and
then we can build a better future together.
Frequently Asked Questions |
Q1:When can I get the quotation ?
A1:We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the
price, please call us or tell us in your email so that we will regard your inquiry priority.
Q2:How can I get a sample to check your quality?
A2:After price confirmation, you can require for samples to check our quality.
If you need the samples, we will charge for the sample cost .But the sample cost can be
refundable after order confirmation when your quantity of the order is more about the MOQ.
Q3:How long can I expect to get the sample?
A3:Sample will be 7days.
Q4:What is your MOQ?
A4:200pcs for each item, we accept little trial order.
Q5:What about the lead time for mass production?
A5:Honestly, it depends on the order quantity and the season you place the order. The lead time
is about 20 days. Generally speaking, we suggest that you start inquiry two months before the
date you would like to get the products at your country.
Q6: What is your terms of delivery?
A6: We accept EXW, FOB, CIF, etc. You can choose the one which is the most convenient or
cost effective for you.
