High accuracy stainless steel miniature ball bearing MF52ZZ for miniture race cars
- 5000 Piece / Pieces per Month
- Shanghai
- T/T
-
High Performance Miniture Flange Ball Bearing F682ZZ
-
mini ball bearing MF128ZZ flange bearing
-
flange bearing F607ZZ mini ball bearing
-
mini ball bearing F689ZZ flange bearing
-
with flange miniature bearing F685ZZ flange bearing
-
6 * 11 * 3mm bore sizes MF117ZZ C4 clearance miniature flanges ball bearing with shields for electric tools
Product Details
| Brand Name: | independent brand | Bore Size: | 5, | Outside Diameter: | 2, |
| Model Number: | bearing MF52ZZ | Precision Rating: | Abec-1, Abec-3, Abec-5, Abec-7 | Seals Type: | zz,rs,rz |
| Number of Row: | Single Row | Place of Origin: | Jiangsu, China |
Packaging Details
Original package, Neutral package.(Single package), Wooden package + pallet; Carton package + pallet.
Product Description
High accuracy stainless steel miniature ball bearing MF52ZZ for miniture race cars
Many ball bearings have flanges as options to their configurations. The flange is designed to aid in mounting and positioning. This is especially true for miniature and instrument bearings but applies to other ball bearing types. Flanges are also used with bearings on external housings used to mount a bearing unit. A mounted bearing unit acts as a system to position the bearing securely for reliable operation.
Some models for your reference:
| flange (D1) | Breadth(B) | flange breadth(c) | Cr(N) | Cor(N) | speed | |||||||
| Model | (d) | (D) | open | zz | open | zz | open | zz | grease | oil | ||
| *1000rpm | ||||||||||||
| F682zz | 5 | 6.1 | 1.5 | 2.3 | 0.5 | 0.6 | 169 | 50 | 85 | 100 | ||
| MF52zz | 2 | 5 | 6.2 | 2 | 2.5 | 0.6 | 0.6 | 169 | 50 | 85 | 100 | |
| F692zz | 6 | 7.5 | 2.3 | 3 | 0.6 | 0.8 | 330 | 99 | 75 | 90 | ||
| MF62zz | 6 | 7.2 | 2.5 | 2.5 | 0.6 | - | 330 | 99 | 75 | 90 | ||
| MF72zz | 7 | 8.2 | 2.8 | 3 | 0.6 | 0.6 | 386 | 129 | 63 | 75 | ||
| F602zz | 7 | 8.5 | 2.8 | 3.5 | 0.7 | 0.9 | 386 | 129 | 60 | 71 | ||
| F682Xzz | 6 | 7.1 | 1.8 | 2.6 | 0.5 | 0.8 | 209 | 74 | 71 | 80 | ||
| F692Xzz | 2.5 | 7 | 8.5 | 2.5 | 3.5 | 0.7 | 0.9 | 386 | 129 | 63 | 75 | |
| MF82X | 8 | 9.2 | 2.5 | - | 0.6 | - | 558 | 180 | 60 | 67 | ||
| F602Xzz | 8 | 9.5 | 2.8 | 4 | 0.7 | 0.9 | 552 | 177 | 60 | 71 | ||
| MF63zz | 6 | 7.2 | 2 | 2.5 | 0.6 | 0.6 | 209 | 74 | 71 | 80 | ||
| F683zz | 3 | 7 | 8.1 | 2 | 3 | 0.5 | 0.8 | 311 | 112 | 63 | 75 | |
| MF83zz | 8 | 9.2 | 2.5 | 3 | 0.6 | - | 395 | 141 | 60 | 67 | ||
| F693zz | 8 | 9.5 | 3 | 4 | 0.7 | 0.9 | 558 | 180 | 60 | 67 | ||
| MF93zz | 9 | 10.2 | 10.6 | 2.5 | 4 | 0.6 | 0.8 | 571 | 189 | 56 | 67 | |
| F603zz | 9 | 10.5 | 3 | 5 | 0.7 | - | 571 | 189 | 56 | 67 | ||
| F623zz | 10 | 11.5 | 4 | 4 | 1 | 1 | 631 | 219 | 50 | 60 | ||
| MF74zz | 7 | 8.2 | 2 | 2.5 | 0.6 | 0.6 | 255 | 108 | 60 | 67 | ||
| MF84zz | 4 | 8 | 9.2 | 2 | 3 | 0.6 | 0.6 | 395 | 141 | 56 | 67 | |
| F684zz | 9 | 10.3 | 2.5 | 4 | 0.6 | 1 | 641 | 227 | 53 | 63 | ||
| MF104zz | 10 | 11.2 | 11.6 | 3 | 4 | 0.6 | 0.8 | 711 | 272 | 48 | 56 | |
| F694zz | 11 | 12.5 | 4 | 4 | 1 | 1 | 957 | 350 | 48 | 56 | ||
| F604zz | 12 | 13.5 | 4 | 4 | 1 | 1 | 957 | 350 | 48 | 56 | ||
| F624zz | 13 | 15 | 5 | 5 | 1 | 1 | 1301 | 488 | 40 | 48 | ||
| F634zz | 16 | 18 | 5 | 5 | 1 | 1 | 1340 | 523 | 36 | 43 | ||
| MF85zz | 8 | 9.2 | 2 | 2.5 | 0.6 | 0.6 | 218 | 90 | 53 | 63 | ||
| MF95zz | 5 | 9 | 10.2 | 2.5 | 3 | 0.6 | 0.6 | 431 | 169 | 50 | 60 | |
| MF105zz | 10 | 11.2 | 11.6 | 3 | 4 | 0.6 | 0.8 | 431 | 169 | 50 | 60 | |
| MF115zz | 11 | 12.5 | - | 4 | 0.8 | 1 | 716 | 282 | 45 | 53 | ||
| F685zz | 11 | 12.5 | 3 | 5 | 0.8 | 1 | 716 | 282 | 45 | 53 | ||
| F695zz | 13 | 15 | 4 | 4 | 1 | 1 | 1077 | 432 | 43 | 50 | ||
| F605zz | 14 | 16 | 5 | 5 | 1 | 1 | 1329 | 507 | 40 | 50 | ||
| F625zz | 16 | 18 | 5 | 5 | 1 | 1 | 1729 | 675 | 36 | 43 | ||
| F635zz | 19 | 22 | 6 | 6 | 1.5 | 1.5 | 2336 | 896 | 32 | 40 | ||
| MF106zz | 6 | 10 | 11.2 | 2.5 | 3 | 0.6 | 0.6 | 496 | 218 | 45 | 53 | |
| MF126zz | 12 | 13.2 | 13.6 | 3 | 4 | 0.6 | 0.8 | 716 | 295 | 43 | 50 | |
| F686zz | 13 | 15 | 3.5 | 5 | 1 | 1.1 | 1082 | 442 | 40 | 50 | ||
| F696zz | 15 | 17 | 5 | 5 | 1.2 | 1.2 | 1340 | 523 | 40 | 45 | ||
| F606zz | 17 | 19 | 6 | 6 | 1.2 | 1.2 | 2263 | 846 | 38 | 45 | ||
| F626zz | 19 | 22 | 6 | 6 | 1.5 | 1.5 | 2336 | 896 | 32 | 40 | ||
| MF117zz | 11 | 12.2 | 2.5 | 3 | 0.6 | 0.6 | 455 | 202 | 43 | 50 | ||
| MF137zz | 13 | 14.2 | 14.6 | 3 | 4 | 0.6 | 0.8 | 541 | 276 | 40 | 48 | |
| F687zz | 7 | 14 | 16 | 3.5 | 5 | 1 | 1.1 | 1173 | 513 | 40 | 50 | |
| F697zz | 17 | 19 | 5 | 5 | 1.2 | 1.2 | 1605 | 719 | 36 | 43 | ||
| F607zz | 19 | 22 | 6 | 6 | 1.5 | 1.5 | 2336 | 896 | 36 | 43 | ||
| F627zz | 22 | 25 | 7 | 7 | 1.5 | 1.5 | 3287 | 1379 | 30 | 36 | ||
| MF128zz | 12 | 13.2 | 13.6 | 2.5 | 3.5 | 0.6 | 0.8 | 543 | 274 | 40 | 48 | |
| MF148zz | 14 | 15.6 | 3.5 | 4 | 0.8 | 0.8 | 817 | 386 | 38 | 45 | ||
| F688zz | 8 | 16 | 18 | 4 | 5 | 1 | 1.1 | 1252 | 592 | 36 | 43 | |
| F698zz | 19 | 22 | 6 | 6 | 1.5 | 1.5 | 2237 | 917 | 36 | 43 | ||
| F608zz | 22 | 25 | 7 | 7 | 1.5 | 1.5 | 3293 | 1379 | 34 | 40 | ||
| F689zz | 9 | 17 | 19 | 4 | 5 | 1 | 1.1 | 1327 | 668 | 36 | 43 | |
| F699zz | 20 | 23 | 6 | 6 | 1.5 | 1.5 | 2467 | 1081 | 34 | 40 | ||
| F6700zz | 15 | 16.5 | 16.5 | 3 | 4 | 0.8 | 0.8 | 850 | 430 | 14 | 16 | |
| F6800zz | 10 | 19 | 21 | 5 | 5 | 1 | 1 | 1700 | 800 | 35 | 42 | |
| F6900zz | 22 | 25 | 6 | 6 | 1.5 | 1.5 | 2611 | 1223 | 31 | 40 | ||
| F6701zz | 18 | 19.5 | 19.5 | 4 | 4 | 0.8 | 0.8 | 922 | 512 | 12 | 14 | |
| F6801zz | 12 | 21 | 23 | 5 | 5 | 0.8 | 1 | 1911 | 1041 | 33 | 39 | |
| F6901zz | 24 | 26.5 | 6 | 6 | 1 | 1.5 | 2831 | 1411 | 31 | 36 | ||
