Chrome Steel : Brass Cage 4"x5 1/2"x3/4" Thin Section Bearing Open Ball BearingsVF040CP0 /VF040CP0 Ball Bearing

Original package, Neutral package.(Single package), Wooden package + pallet; Carton package + pallet. Or as your requirements

Specifications

thin-section bearing:
1. High accuracy
2. Low noise
3. Oil Preservative
4.be customized

    Chrome Steel : Brass Cage 4"x5 1/2"x3/4" Thin Section Bearing Open Ball BearingsVF040CP0 /VF040CP0 Ball Bearing

• VF040CP0 Thin Section Open Ball Bearing with a 3/4" cross section width, VF040CP0 bearing is a popular item that could be used in many applications, the dimensions are 4" x 5 1/2" x 3/4" inch, VF040CP0 bearing has Brass balls retainer, VF040CP0 bearing is oil preserved.

  • Item: VF040CP0 Ball Bearing
  • Type: Deep groove Radial Ball Bearing
  • Material: Chrome Steel
  • Cage: Brass
  • Closures: Open
  • Dimensions: 4" x 5 1/2" x 3/4" Inch
  • ID (inner diameter)/Bore: 4" inch
  • OD (outer diameter): 5 1/2" inch
  • Width/Height/thickness: 3/4" inch
  • Size: 4" x 5.5" x 0.75"
  • Cross Section: 3/4" inch
  • Dynamic load rating: 28260 N
  • Static load rating: 12994 N
  • Quantity: One Bearing
  • Equivalents: KF040CP0, SF040CP0, KF040CPO and SF040CPO

Specifications of some thin section ball bearings



KCseries				Weight(kg)	Interchang
Dimension(inch)		Basic Cap.N			KAYDON
d	D	Cor	Cr
6.000	6.750	13650	5070	0.295	KC060CP0
6.500	7.250	14710	5330	0.312	KC065CP0
7.000	7.750	15780	5560	0.340	KC070CP0
7.500	8.250	16850	5820	0.360	KC075CP0
8.000	8.750	17910	6050	0.387	KC080CP0
9.000	9.750	20050	6530	0.450	KC090CP0
10.000	10.750	22180	6980	0.481	KC100CP0
11.000	11.760	24310	7420	0.526	KC110CP0
12.000	12.750	30720	8670	0.567	KC120CP0
14.000	14.750	30720	8670	0.689	KC140CP0
16.000	16.750	35030	9470	0.785	KC160CP0
18.000	18.750	39290	10220	0.880	KC180CP0
20.000	20.750	43560	10980	0.980	KC200CP0







We are a Energetic Bearing company with more than 10 years experience in Shandong factory .

We mainly deal in : Deep groove ball bearing , Angular contact ball bearing , Taper roller bearing , Cylindrical roller bearing , Pillow Block bearing ,  Ceremic Ball bearing  , OEMService also welcomed .



Customers Spoke highly to our high quality with competitive price , and good service . We always stick to the principle : “Treat customers wholeheartly” and making progress .
