Features:
Rubber automatic deflashing machine:
The Wellgreen SpinTrim is a simple and cost-effective method of deflashing small rubber parts. It can be used as a single process operation or as a cost reducing first stage before cryogenic deflashing for excessive flash.
- An affordable system of mechanically deflashing rubber parts that provides quick pay back & improved finish quality.
- A very compact and quick solution for the deflashing of rubber parts.
- A simple method of operation and exceptionally easy to maintain.
- A system that eliminates safety risk and time taken with manual trimming.
- Range of horizontal type products: O-ring /gasket / rubber seal parts /sundries and all the products which could be processed by hand .
Specification:
- For loads of a maximum of 1-2 kg.
- Adjustable cycle time
- High quality PLC and inverter
- English-language colour operator interface angled for easy viewing
- Insulated for sound reduction
- Auto water spray and dust collect function
- Touching screen & inverter with automatic memory function
- This device security and stability ,easy operation and long life
- Productiong of different products with ou changing the mold .just for the utility model products corresponding parameter adjustment to the process of using performance more stable and reliable :processing of the product defect-free,continuous operation, the whole process automatic control system
- A single device is equivalent to 10-20 times the manual operation mode
- The utility model of these improvements , making the rubber automatic demolition edge machine operation easier and safer production ,efficiency is greatly improved a lot
| Brand name | Wellgreen |
| Motor Power | 4kw |
| Motor speed | 28760 r/min |
| Range of hardness | 30°-90° |
| T Maximum load | 2kg |
| Air compression | 0.4Mpa 0.67L/min |
| Overall dimension(LxWxH) | 1750x800x1200mm(deflashing machine) |
| Power supply | 380(220/415)V/3PHASE/50(60)HZ |
| Overall dimension(LxWxH) | 1350x700x700mm(separator) |
| Motor power of separator | 0.25kw |
| Total weight | 510KG |
