Specifications
Graphite Bushings:1.high strength;
2. high load capacity;
3. solid lubricant;
4. high temperature resistant
Solid Bronze Bush, Graphite Bushings
This graphite embedded bushing is a kind of high strength cast bronze based material and on the surface of ehich is embedded with preformed solid lubricant. The JDB bushes has both the virtues of the copper alloy and the solid lubricant, can be applied under dry, high temperature, high pressure, corrosive, water or other chemical environment, where no oil can be introduced. This bushes is now used in successive casting machinery, steel rollers in metallography, mineral machinery, ships, turbogenerators, hydraulic turbines and injuection molding machinery for plastics. We can make all sizes and types of this bushes, also by clients requests!
The specification of this bushes as follows:
Material: High-strength and Graphite;
Load Capacity: 150N/mm2;
Temperature Limit: -100~+300;
Max. Sliding Velocit: 1.5M/s;
Friction Clef: 0.05~0.25;
PV Limit(dry): 3.3N/mm2*m/s;
PV Limit(oil): 16N/mm2*m/s.
Features:
- Exhibits incomparable performance under high load, low speed operation. Usable without lubrication.
- Excellent wear resistance in such places where an oil film is difficult to be formed due to reciprocating, oscillating motions and frequently intermittent operations.
- Remarkable resistance to corrosion and resistance to chemical attack.
- Available in various dimensions as standard or customized product
we can supply self-lubeicating bearing&bushing
Some models for your reference:
| Type | SF-30 | SF-31 | SF-32 | SF-33 | SF-34 | |
| Performance index | ||||||
| Max Load Capacity(N/mm2) | 150 | 130 | 130 | 120 | 100 | |
| Tensile Strength(N/mm2) | 185 | 150 | 150 | 200 | 200 | |
| Max Sliding Speed (Oil Lubrication) | 5 | 10 | 10 | 15 | 25 | |
| V(m/s) | ||||||
| Friction Coefficient μ | 0.06~0.14 | 0.06~0.16 | 0.06~0.16 | 0.08~0.16 | 0.08~0.17 | |
| N/mm2·m/s | Grease Lubrication | 2.8 | 2.8 | 2.8 | 2.5 | — |
| Max PV Value Limit | Oil lubrication | 10 | 10 | 10 | 8 | 6 |
| Material | JF-800 | Steel+Bronze(CuSn10Pb10) |
| JF850 | Steel+ Bronze(CuSn6Zn6Pb3) | |
| JF-720 | Steel+ Bronze(CuSn4Pb24) | |
| JF-20 | Steel+ Bronze(AlSn20Cu) | |
| JF700 | Steel+ Bronze(CuPb30) | |
| Load capacity | 150N/mm2 | |
| Speed limit | Oil lubricating | 2.5m/s |
| Dry Friction | 0.4m/s | |
| PV value limit | Oil lubricating | 10N/mm2.m/s |
| Dry friction | 2.8 N/mm2.m/s | |
| Mating axis required | Hardness | >=48~53HRC |
| Roughness | Ra=0.16~0.63 | |
| Friction coef | 0.05-0.22 | |
| Working temperature max. | 200°C |
We offer OEM service.
Why I choose you?
Profession and reliability. Everyone likes to blow big bubbles. But we need to be honest with ourselves. We maybe not the most handsome, but we have a heart like fire. To meet the morning sunshine, to enjoy our work every day. Say what we mean and mean what we said is our words to ourselves. We work for our family.
How long are their lifetime?
My friend, with your gentle care,6 months to 36 months for different products.
How to deal with the quality problem?
Congratulation! You must be winning lottery!
You will get helps by beautiful ladies from our QC terms. There will be discount, secret gifts, of course the new bearings waiting for you.
On the other hand, we have a PPAP of each shipment, so that we know
Which shipment is bad? We will cut off production line and avoid more loss.
Can you take responsibility for me?
Of course, I’m happy to help you! But I just take responsibility for my products. We are not willing to see the quality issues, but if happen this problem we will deal with them according to the actual situation.
Can you give me discount?
Yes, of course. If you talk with us, you’ll get more.
Will you send me free sample?
Yeah, she'd love to; can you buy her a ticket?
What should I do if the bearing rusted in her trip?
Oh, bad weather, the bearing must be very sad for her face.
Don't worry; you'll have the new one.
Do you like to serve the client only with small orders?
We enjoy to grow up together with all our clients whatever big or small.
