CFTV heat shrink tube

FOB Price

USD $0.5 - $5.55 / Meter

122 Meters(Min.Order)

Supply Ability 10000 Meter / Meters per Month
Port Dalian
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	China	Brand Name:	UPM	Model Number:	S3TV
Type:	Insulation Sleeving	Material:	PE	Application:	Low Voltage
Rated Voltage:	1kV	Tensile Strength:	10.4

Product Description

Specifications

Shrink ratio of 3 to 1
Absolutely waterproof seal
Raychem/Tyco :TCS2
heat shrink tube
CFTV heat shrink tube

CFTV heat shrink tube

DSG canusa CFTV

S3TV Medium Wall Halogen-Free Heat Shrinkable Tubing for CATV industry

Developed to meet the specific needs of the CATV Industry

Application

Heat Shrinkable Tubing and adhesive liner combination that established the CATV industry standard for splice and connector protection

Features

Shrink ratio of 3 to 1

An absolutely waterproof seal

Environmentally seals and mechanically protects

7 standard sizes

Adhesive flows smoothly and will not drip

Selective strip ability to meet CATV industry needs

Fast and simple installation

Minimal heat required to produce error free installation without splitting

Heat indicative paint ensures integrity of seal

Installation Tests

When adequate heat is applied, heat reactive stripes change color: green to black

When color has changed, tubing is fully recovered, sealant has achieved balanced flow

Adhesive flows without dripping

No cracks or splitting

No surface charring during installation

Temperature Range

operating temperature:-55 ~ 110°C

Shrink temperature: 120°C

Color Black

Product Code Cross References

Raychem/Tyco :TCS2

DSG Canusa :CFTV

3M :CCT

LG :LG-CATV

Technical Details

Test item	Test method	Typical value
Tensile Strength	ASTM D2671	12Mpa
Elongation	ASTM D2671	400%
Specific Gravity	ASTM D792	1.15
Elongation after Heat Aging(168 hrs at 150)	ASTM D2671	350%
Tensile strength after heat aging	ASTM D2671	12Mpa
Low Temperature Flexibility(4 hrs at -55)	ASTM D2671	No cracking
Hardness (Shore D)	ASTM D2240	60D
Heat shock (4hrs at 200)	ASTM D2671	No cracking or flowing
Adhesive Softening Point	ASTM-E28	85
Adhesive Peel Strength to P.E.	ASTM D1000	110N/25mm
Adhesive Peel Strength to Aluminum	ASTM D1000	80N/25mm
Dielectric Strength	ASTM D2671	20kV/mm
Volume Resistivity	ASTM D257	10¹⁴Ω.cm
Copper Corrosion	ASTM D2671	No Corrosion
Water Absorption	ASTM D570	0.5%
Fungus Resistance	ASTM G21	No Growth

Product Selection

Product Code	IDbefore shrink(mm)	I Dafter shrink(mm)	Min.Wall thickness After shrink(mm)	Normal length/pc(meter)
S3TV 0400(12/4)	12	4	2.0	1.22
S3TV 0750(19/6)	19	6	2.5	1.22
S3TV 1100(28/9)	28	9	2.5	1.22
S3TV 1300(33/10)	33	11	2.5	1.22
S3TV 1500(38/12)	38	12	2.5	1.22
S3TV 1700(43/12)	43	12	2.5	1.22
S3TV 2050(55/16)	55	16	2.7	1.22
S3TV 2750(75/22)	75	22	3.0	1.22

ID: Internal Diameter
