High Voltage Class Heat Shrink Sleeves

US$ 0.56 - 5.99 MOQ: 200 Meters

Key Specifications

Place of Origin:

Liaoning, China

Brand Name:

UPM

Model Number:

S3c

Union Polymer Material Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Liaoning, China

Brand Name UPM

Model Number S3c

Specifications

pipe heat shrinkable tubing
Mastic glue heat shrinktube
Anti corrosion
Underground pipe work application
Shrink ratio :3:1

pipe heat shrinkable tubing

S3(c) HDPE Anti-Corrosion black mastic Dual Wall Heat Shrinkable Tubing

Cross linked dual wall HDPE heat shrinkable tubing with self-priming mastic sealant inner layer

containing an active corrosion inhibitor. Desigened to prevent corrosion and protect metal pipelines

and soil anchors.

Features/Benefits

Shrink Ratio: 3:1

Adhesive-lined, sealing against water and moisture

Corrosion resistant to common chemical solutions

Abrasion resistant

Applicable in direct underground pipe work applications

Temperature Range

Operating Temperature : -55 ~ 135 ºC

Shrink Temperature : 135 ºC

Color:Black

Product Code Cross References

Raychem/Tyco : SATM

DSG Canusa : PLA

Technical Details

Test Item	Test Method	Typical Data
Tensile strength	ASTM D 2671	> 17Mpa
Elongation at break	ASTM D 2671	> 400%
Impact brittleness	ISO 974	< -40
Water Absorption (23 for 24h)	ISO 62	< 0.1%
Peel strength to steel at 23 (cross head speed 100mm/min)	ISO 4587	> 4N/cm²
Soften point	ASTM E28	>70
Shear strength at 23 (cross head speed 50mm/min)	ISO 4587	>10N/cm²

Production Selection

Product Code	Min. wall thicknessafter free recovery(mm)	Standard Length Per Piece(m)
S3(c)-Φ30/10	2.9	1.22
S3(c)-Φ37/12	3.0	1.22
S3(c)-Φ45/22	2.7	1.22
S3(c)-Φ55/22	2.7	1.22
S3(c)-Φ75/25	3.2	1.22
S3(c)-Φ80/28	3.2	1.22
S3(c)-Φ95/36	3.3	1.22
