UPM Heat Shrink S2(n) Thin Wall Heat Shrink Sleeve
- Dalian
You May Like
-
Kynar 175 Degree Electrical Heat Shrink Tubing
-
Rubber Pipe Protective Heat Shrink Sleeve With Air Groove
-
Clear Kynar Shrink Tubing
-
Electronic Heat Shrink Thin Wall Heat Resistant Tubing for General Purpose
-
S5 PVDF Clear Heat Shrinkable Tubing
-
UPM Heat Shrink S2(n) Thin Wall Heat Resistant Tubing for General Purpose
Product Details
| Place of Origin | Liaoning, China | Brand Name | UPM heat shrink | |
| Model Number | S2(n) | Type | Insulation Sleeving | |
| Material | Other, PE, cross linked Polyolefin | Application | Low Voltage | |
| Rated Voltage | 600V | Tensile Strength | 10.4 |
Product Description
Specifications
Shrink Ratio: 2:1 3:1thin wall tubing and low shrink temperature
Flame retardant VW-1 Ideal for wire and cable labeling
S2(n) Halogen Free Thin Wall Cross-linked Polyolefin for General Purpose
Features:
1. Insulation, Protection,Identification
2. Flame retardant VW-1(except clear)
3. Halogen free, flexible
4. Wide range of colors
5. Operating temperature: -40~125 °C
6. Shrink temperature: 125 °C
7. Shrink Ratio:2:1 & 3:1
8. Voltage Class:600-1000 V
Approvals: UL approval UL file no. E236437
Typical application:
1. Ideal for electrical insulation,strain relief,wire bonding and light harness jacketing
2. Common applications include electronic systems of subway, aircraft, submarine , control room facilities and sealed environments
Ordering :
Standard color : Red,Blue, Yellow, Green, Black, Clear
Special colors are available on request
Spools as standard, cutting pieces or assorted kits are available on request
Cross reference:
Raychem/Tyco : Versafit V2/ RNF 100
