Precision Trachea Cannula Medical Pipe making machine
- 10 Set / Sets per Month
- Shenzhen or Guangzhou
- CNC router for stone processing engraving machine
- Glass polishing machine JMB95A
- Aluminum Profile Bending Machine/Arc Bending Machine for Aluminum
- Automatic aluminum window corner connector cutting machine
- aluminum door and window frame cutting machine aluminum windows and doors machine
- Upvc Window Door Machine Four Head Welding Machine for PVC welding Window Machine
Product Details
Condition: | New | Type: | Other, medical pipe | Pipe Material: | PVC |
Application: | Other, medical pipe | Production Capacity: | 15-25kg/h | Place of Origin: | Guangdong, China |
Brand Name: | SONGHU | Model Number: | SHSJ-45&25 | Voltage: | 380V |
Power(W): | 30KW | Dimension(L*W*H): | 12*1.5*1.8m | Weight: | 1500KG |
Certification: | CE Certificate | Warranty: | 12months, 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
About product:
Precision of PVC/PU endotracheal intubation extrusion production line is mainly used in the
production of 2.5 mm to 2.5 mm clinical common trachea inserted, reinforced tracheal
intubation, special-shaped endotracheal intubation, wire endotracheal intubation, special-shaped steel wire endotracheal intubation, trachea cut cannula, double lumen endobronchial
intubation; Applicable materials: medical grade PVC, PP, PE, PU.
Main features:
Precision medical tube extrusion line is stable and efficient, especially its voltage, hydraulic,
pneumatic, extrusion and traction speed are digital control when producing process.The
roundness and wall thickness have reached a high standard of ± 0.02mm.
Machine includes:
Model | Equipment | Quantity |
1 | 45mm main extruder | 1 SET |
2 | 25mm co-extruder | 1 SET |
3 | Precise mould | 1 SET |
4 | 4 meters water tank | 1 SET |
5 | Haul-off | 1 SET |
6 | Cutter | 1 SET |
Precision extruder:
1.Mechanical structure:frame bottom and whole thickened plate make volume weight and lower center of gravity, ensure the machine running stability.
2.Power system: Electric part adopts Japan Fuji inverter control, the main motor adopts Siemes motor, power system is stable and reliable.
3.Temperature control: Temperature control adopts Japanese OMRON intelligent temperature
control meter, intelligent control of double PID, using solid state relay, control process is more quiet and reliable.Air-cooling adopts centrifugal multi-blade fan,no noise while big air volume.
4.Extrusion mould: Extrusion mould adopts imported heat stability of S136 special extrusion
die steel, mirror the flow path, to provide protection for the high quality products.
Water tank:
1.Mechanical structure:Made of SUS304 stainless steel, full toughened glass closed structure
with sealing plates around.This water tank is specially for medical dust-free condition.
2.Three-dimensional regulating system:
adopts rail regulation,which is convenient,smooth and good straightness, and adjusted by four
screw adjustment from top to bottom,allows the cooling tank more stable and small vibration.
3.Centrifugal pump is for medical grade deionized special stainless steel water pump, sizing
cooling method of uniform water ring type and degree of vacuum can be digital control. Sizing and cooling method of uniform water ring type and degree of vacuum can be digital control.
Haul-off:
The haul-off system is using PU flexible multi wedge belt, high precision line guides opening
and closing, long down regulation mechanism, German Siemens Servo motor and controller,
imported synchronous belt transmission mode, which can effectively overcome using gear rotates or slight shock due to gear rotates over the tooth,which ensure the haul-off speed more
stable and provide the guarantee for high quality products.
Main technical parameter:
Model
| Screw Dia. | Screw L/D | Motor power | Haul-off power | Cutter power | Capacity(kgs/hr.) |
SHQC-45&25 | 45&25 | 25-30 | 7.5kw | 1.5 | 5 | 15-20 |
Product samples:
Service:
Pre-sale service
1. Our principle is to give customers peace of mind,such as making investment budget,
manufacturing planning, training operation staff,etc. so that customers make a reasonable plan with less cost.
2. Investment budgeting: We provide services of product profit analysis, recommendation of
machine and auxiliary equipment and relevant budgeting, human resources allocation and
budgeting.
3. We provide the mounting dimension of the equipment base, design of equipment layout,
workshop ventilation, water transmission etc.
In-sale service
1. Detailed design of lay-out that is the position of the procession
2. Technological information of provided products
3. Schedule about design,manufacturing and installation
4. Working & Producing progression
After-sales service
1. The supplier provide service manual and maintenance instruction of main electric appliance,
limb,usage manual of equipment.We also supply water,electricity,gas of equipment and
installation drawing.
2. The supplier is responsible for installation,debugging and training, but the air tickets,
insurance,eating,housing and every day 50 USD for each engineer will be payed by the buyers.
3. Fittings of the machine will be supplied at preferential price after one year .
About Songhu:
Songhu plastic machinery Co., Ltd is a professional equipment manufacturer combined with theprecision extrusion technology, production and marketing. We got the international CE
certificate, 4 national invention patents and 12 utility patents . Since we set up, our clients are
widely from home and aboard, such as Italy, South Korea, Spain and Russia etc., we have more than 80% domestic market share in China.
There are more than 20 sets of various kinds of advanced processing and testing equipment, 20 precision extrusion lines for customers’ test are available and a number of experienced
engineer in our 8,000 square meters factory. We are not only provide precision medical tube
extrusion line but also produce 3d printer filament extrusion line, industrial pipe extrusion line, plastic rattan extrusion line and plastic profile extrusion line etc..
Contact us:
If you have any question or you are interested in our machine, please contact us without
hesitation and you also can view on our website.
