Help CenterElectric Soldering Station for String Solar Cell Quality Choice
Related Products
-
Crimping Tool for Connecting MC4 Conectors and PV Cable,stainless Steel MaterialUS$ 25 - 30MOQ: 1 Set -
Wire Crimping Tools for Connectors and Terminals, Solar Cable Crimping PlierUS$ 25 - 30MOQ: 1 Set
-
Hand Crimping Tools for MC3 Solar Power Connectors,easy to Use and Long Life With Conpetitive PriceUS$ 32 - 37MOQ: 1 Piece
-
Crimping Tools for MC Solar Connector,easy to Use and Save EnergyUS$ 32 - 37MOQ: 1 Piece
-
Cable Crimping Tool for Solar Connector MC3&MC4,2016 NEW Style,hot Sale in IndiaUS$ 32 - 37MOQ: 1 Piece
Specifications
Specially for soldering solar cell.
Heatting quickly;
Reduce breakage rate of solar cell;
Reduce weakening of solar cell.
Lead free soldering station for solar cell
The excellent performance of lead free soldering station
Specially for soldering solar cell lead free.
Heatting quickly;
Reduce breakage rate of solar cell;
Reduce weakening of solar cell percent conversion;
The extraordinary ability of heat recovery
It takes less than 20 seconds from room temperature to 300°C
The intelligentized perfect soldering
It can avoid the insecure joint caused by cold soldering.
The miraculous temperature compensation speed can solve the temperature contradiction during the process of lead free soldering. It is an edge tool of lead free soldering and a necessary of soldering under specific low temperature conditions
To extend the life of solder tip
The relatively decrease of soldering soldering temperature extend the using life of solder tip greatly.
Practical function
1. Automatic sleep, energy saving
The soldering station will decrease the temperature to 200°C automatically if you don't use the soldering iron more than 20 minutes. When you take the soldering iron, the temperature will return back quickly. It can also extend the life of solder tip.
2. Password lock temperature
The steady soldering temperature is a guarantee of soldering quality. the soldering station can lock temperature with password conveniently. Others can not change the temperature randomly.
3. The fission structure of heater and solder tip
The design of fission structure can avoid the unnecessary loss cased by the unite of heater and solder tip completely, which can cut down the expenditures and decrease the energy loss.
Performance parameter
|
Performance parameter
|
Q 203 |
Q 203H |
Q K204 |
Q 204H |
936 Series |
|
||
Temperature adjustment range |
50°C-600°C |
50°C-600°C |
200°C-420°C |
200°C-420°C |
200°C-480°C |
|
||
Temperature stability (no-load) |
±2°C |
±2°C |
±2°C |
±2°C |
±1°C |
|
||
The input voltage, frequency |
220V/110V 50Hz/60Hz |
220V/110V 50Hz/60Hz |
220V/110V 50Hz/60Hz |
220V/110V 50Hz/60Hz |
|
|
||
The input voltage, frequency |
36VAC 400KHz |
36VAC 400KHz |
36VAC 400KHz |
36VAC 400KHz |
24VAC 50Hz |
|
||
maximum power |
60W |
90W |
60W |
90W |
60W |
|
|
|
heating up time(20°C-350°C) |
35S |
25S |
35S |
25S |
60S |
|
||
Temperature compensation speed |
Fast |
Most fast |
More fast |
Very fast |
Normal |
|
||
Temperature drop |
30°C |
20°C |
30°C |
20°C |
50°C |
|
||
heating method |
intelligent |
intelligent |
|
|
|
|
||
Heating principle |
HFEC |
HFEC |
HFEC |
HFEC |
resistance-type |
|
||
Soldering pen of resistance head |
< 2Ω |
< 2Ω |
< 2Ω |
< 2Ω |
< 2Ω |
|
||
Soldering pen of potential head |
<2mv |
<2mv |
<2mv |
<2mv |
<2mv |
|
||
Auto sleep function |
yes |
yes |
no |
no |
no |
|
||
Temperature lock method |
Password lock |
Password lock |
mechanical
|
mechanical
|
mechanical
|
|
||
Anti-static shell |
Aluminum shell, firm and durable |
Aluminum shell, firm and durable |
Aluminum shell, firm and durable |
Aluminum shell, firm and durable |
Plastic shell, Antistatic coating |
|
||
