Home > Products > pellet mill > SZLH508 Feed Pellet Machine
SZLH508 Feed Pellet Machine
- ShangHai
- T/T
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | DarChee | Model Number | SZLH508 | |
| Type | Feed Pellet Machine | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
SZLH508 Feed Pellet Mill/ Wood Pellet Mill/Machine
our Biomass Pellet Mills are used for pelletizing such as wood chips, sawdust, rice husks, wheat straw, cotton straw, bagasse, marigold and grass.
1.Frequency conversion motor regulates the feeding rate. Feed screw is with variable helical structure, controlling precisely.
2.Conditioner body with large opening-door structure is easy for checking and maintenance;
3.The conditioner is set with spraying nozzles, they will add proper water to make the raw materials to achieve the best effect.
4.Setting a discharging handle or a pneumatic discharging on the outboard, makes it easy for the operation of automatic control.
5.Fit with a ring dies lifting device, which is easy to disassemble ring dies and reduce labor intensity.
6.Larger mills adopt the magnetic filtering to remove more impurities.
7.The cooling and the oil cutting alarm are in one oil cooling lubrication system, forcibly lubricating the main bearing.
8.Different materials are different ring dies running speeds, which will improve the effect of pellets.
Model | Main Power (KW) | Feeder Power (KW) | Conditioner Power (KW) | Die Diameter (mm) | Pellet Size (mm) | Capacity (ton/hour) |
350 | 45-55 | 0.75 | 3 | 350 | 6-10 | 0.5-0.7 |
420 | 90 | 1.5 | 5.5 | 420 | 6-12 | 0.8-1 |
508 | 132/160 | 2.2 | 5.5 | 508 | 6-12 | 1.5-2 |
678 | 185 | 3 | 11 | 678 | 6-12 | 2.5-3.5 |
768 | 250 | 4 | 18.5 | 768 | 6-12 | 4-5.5 |
