Specifications
Burst generator1,Meet the standard:IEC61000-4-4
2,TUV certified
3,Professional manufacture in China
Burst generator EFT61004BG is designed for EFT immunity test requirements . The test is intended to demonstrate the immunity of electrical and electronic equipment when subjected to types of transient disturbances such as those originating from switching transients (interruption of inductive loads, relay contact bounce, etc.).The instrument meets the latest standard IEC61000-4-4 , with high reliability, stable performance, user-friendly design and many other features.
Product characteristic:
Fully compliant with the new standards of IEC61000-4-4
LCD interface display .Chinese or English menu, easy to use
LCD display, Intelligent control,Use the imported high-voltage power supply, Reliable performance
Programmable operation by a key setting
Built-in international standards level parameters, simple
Output waveform meets the requirements of 50Ω and 1KΩ impedance
Impulse injects the phase angle: asynchronous or 0-360 °, free to set
Max output Impulse frequence : 1200KHz
Built-in the RS232 interface ,Remote operated by the optional control software.
Model |
EFT61004BG |
||
Output voltage |
0 .2~± 4.8KV |
||
Pulse frequency |
1kHz---1200kHz ± 10%, adjustable |
||
Pulse polarity |
Positive or Negativeor Switchable |
||
Resistor |
50 Ω± 20% |
||
Rise time |
5ns ± 30% |
||
Impulse duration |
(50Ω) |
50ns ± 30% |
|
(1kΩ) |
35 ns~150 ns |
||
Number of burst |
1~255 |
||
Burst period |
300mS( 0.15—9.99 S adjustable,step 0.01S ) |
||
Coupling path |
Built-in, three phase five line,16A |
||
Working power supply |
AC 220V ± 10% 50/60Hz |
||
Ambient temperature |
15 °C -35 °C |
||
Outline dimensions |
435*420*185 mm |
||
TUV certification
Customers visit our company
Manufacturing shop
On the China Electronic Exhabition
Famous customers of us in China and beyond
