Specifications
Combined emc testing equipment1,Meet the IEC61000-4-5,IEC61000-4-4 testing standards
2,TUV certified
Combined EMC testing interference generator PRM61045B is a multi-functional EMC tester which contains EFT and Lightning surge two functions,product complies with the latest standards IEC61000-4-4 and IEC61000-4-5
Product characteristic:
EFT and SURGE two functions combined into a single, more cost-effective
Built-in international standards level parameters and user models parameters,very convenient
LCD display, Intelligent control,Use the imported high-voltage power supply, Reliable performance
Built-in intelligent couping/decoupling network. Testing safely
Built-in the RS232 interface ,Remote operated by the optional control software.
Model |
PRM61045B |
||||
EFT |
Output voltage |
0.2~± 4800V Positive/Negative//Switchable |
|||
Pulse frequency |
1kHz~1200kHz ± 10%, adjustable |
||||
Resistor |
50 Ω± 20% |
||||
Rise time |
5ns ± 30% |
||||
Impulse duration |
50 Ω load |
50ns ± 30% |
|||
1k Ω load |
35 ns~150 ns |
||||
Number of burst |
1~255 |
||||
Burst period |
300mS ( 0.15~9.99 S adjustable,step 0.01S ) |
||||
EUT coupling path |
three phase five line CDN AC220V,50/60Hz,max 16A |
||||
SUG |
Open -circuit t voltage/short-circuit current |
Waveform parameters parameters of Open -circuit t voltage: 1.2/50 μ s , 0.2~ 6kV |
|||
Surge polarity |
Positive / Negative/Switchable |
||||
Phase |
Synchronism 0 °~ 360 °selectable/Asynchronism |
||||
Output impedance |
Complex impedance: 2 Ω |
||||
Coupling path |
three phase five line CDN AC220V,50/60Hz,max 16A |
||||
Surge count |
1~9999 |
||||
Surge interval |
10~9999s |
||||
Working power supply |
AC220V 50/60Hz |
||||
TUV certification
Customers visit our company
Manufacturing shop
On the China Electronic Exhabition
Famous customers of us in China and beyond
