GETWICK Inconel 718 Pipe
- 9 Ton / Tons per Month
- Xi'an/Tianjin/Shanghai/Hong Kong
- T/T D/P D/A Credit Card
- N06625/N07718/N07750/N06601/N06617 Nickel Alloy Bar/Rod Hot/Cold Rolled AISI/ASTM standard
- Haynes 25/2.4819/N06022/NS321/N10276 Nickel Alloy Bar/Rod Manufacturer in China
- N06625/N07718/N07750/N06601/N06617 Nickel Alloy Bar/Rod Hot/Cold Rolled AISI/ASTM standard
- Inconel X718/617/601/600/N06600 Nickel Alloy Bar/Rod AISI/ASTM standard
- Nickel 201/200/N02200/N02201/Inconel X750 Nickel Alloy Bar/Rod Stock in Factory
- Invar36/Alloy31/Alloy20/NS336/NS313 Nickel Alloy Bar/Rod AISI/ASTM standard
Product Details
Place of Origin: | Shaanxi, China | Type: | Nickel Pipe | Application: | heat exchanger,petrochemical,nuclear reactor |
Grade: | Nickel,Choromium,Iron | Ni (Min): | 30% | Powder Or Not: | Not Powder |
Model Number: | Inconel 825/718 | Brand Name: | GETWICK |
Product Description
Specifications
GETWICK Inconel 825 Pipe1.Standard:ASTM B161,ASTM B163
2.Material:n200,n201,inconel,monel
3.certificate: ISO9000:2008
GETWICK Inconel 718 PIpe
Chemical composition
Alloy | % | Ni | Cr | Fe | Mo | Nb | Co | C | Mn | Si | S | Cu | Al | Ti |
718 | Min. | 50 | 17 | balance | 2.8 | 4.75 |
|
|
|
|
|
| 0.2 | 0.7 |
Max. | 55 | 21 | 3.3 | 5.5 | 1 | 0.08 | 0.35 | 0.35 | 0.01 | 0.3 | 0.8 | 1.15 |
minimum mechanical properties in the roomtemperature
Alloy | Tensile strength | Yield strength | Elongation | Brinell hardness HB |
Solution treatment | 965 | 550 | 30 | ≤363 |
Corrosion resistance
718 alloy with extremely resistance to stress corrosion cracking and pitting ability in high temperature or low temperature environments, especially the inoxidability in the high temperature.
The elevated temperature strength, excellent corrosion resistance and workability at 700 C properties made it use in a wide range of high requirement environments.
- Steam turbine
- Liquid-fuel rocket
- Cryogenic engineering
- Acid environment
- Nuclear engineering
