RC260 12v 6000rpm dc motor for motorized toy
- 1000000 Piece / Pieces per Month
- SHENZHEN
- T/T Credit Card
You May Like
-
diameter 22mm dc planetary gear brush motor 12v
-
22mm high torque low rpm 12v dc planetary gear motor
-
customize 24v DC Planerary Gear Motor DPG22-180 diameter 22mm DC motor
-
22mm Small Planetary Gear Motor 6V 12V 24V DC
-
22mm planetary gear motor for medical instrument
-
24v 22mm brush dc planetary gear motor for sliding gate
Product Details
Place of Origin | China | Brand Name | DH Motor | |
Model Number | RC260 12v 6000rpm dc motor for motorized toy | Usage | Boat, Car, Electric Bicycle, Fan | |
Certification | CCC, CE, ROHS, UL | Type | Micro Motor | |
Torque | 10 g.cm | Construction | Permanent Magnet | |
Commutation | Brush | Protect Feature | Drip-proof | |
Speed(RPM) | 4650 RPM | Continuous Current(A) | 0.03A | |
Output Power | 0.477W | Voltage(V) | 12V | |
Efficiency | IE 1 |
Product Description
RC260 12v 6000rpm dc motor for motorized toy
Specification:
1.Rated Voltage:DC 6-15V
2. dc micro vibrating motor 12v RC-260
3. 19.7 g.cm Torque At Max Efficiency
3. Carbon-brush motor
4.Diameter 23.8mm,length 27mm,shaft 2.0mm
5.Application: Hail Clipper/Massager/ R motor/ Rearview Mirror / Office Automitive Equipment/
6.Weight: 28g Approx
a
Dimensions and Parameters
Notice: Our Comany Can customized for your request, Please contact us to know more details.
dc motor with gear box Supplier company in Shenzhen
Question 1:What's your main products?
Answer: Dia10~52mm DC Micro Motor and Gear Motor,Auto dc motor, Electric motor, Gear Motor, DC Motor, Brush DC motor, Brushless DC motor,Spur Gear motor, Micro Motor, Vibration motor etc.
Question 2:What's the main usage of the micro dc gear motor?
Answer:Our motor widely used in Home Appliance,Office Equipment,Health-care appliance,Sanitation industry, High-class toy,Banking System,Electronic and electrical tools,automation industry, bank equipments,payment equipments,vending machines,power door lock,electric door lock.
Question 3:Do you accept customize?
Answer:Sure,as we have a strong design team,any problems will get our technical answer.
Question 4:What kind of data do i neet to provide if i want to order?
Answer:Please kindly tell us your voltage,speed,torque and overall dimension.
Question 5:What if i don't know the above data?
Answer:Please contact our saleman to handle,we'll answer your questions patiently.
We only sale the top-quality item, we can provide the reasonable price since we have fight with the supplier as a lowest cost as we can. Please feel free contact us if any needs and questions about the dc gear motor.
