DC24V High Speed Motor

DC24V High Speed Motor thumbnail-1
DC24V High Speed Motor photo-1
US$ 25 - 200 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
dong hui
Model Number:
high speed motor
Contact Supplier Request Quote Chat Now
Shenzhen Xin Dong Hui Motor Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shen zhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name dong hui
Model Number high speed motor
Usage Home Appliance, Other, Home Appliance, high speed motor
Certification ROHS
Type Gear Motor
Torque 55mN.m
Construction Permanent Magnet
Commutation Brushless
Protect Feature Other, 36mm coreless motor
Speed(RPM) 11300rpm no load
Continuous Current(A) 250mA no load
Output Power 72W
Voltage(V) 24
Efficiency IE 1

Specifications

1.high speed motor
2.24v voltage
3.11300rpm no-load speed
4.high efficiency

Specifications

1.36mm coreless motor
2.24v voltage
3.11300rpm no-load speed
4.high efficiency

36mm coreless motor



Technical data:



36mm coreless motor

rated voltage:24v

No-load speed:11300rpm

No-load current:250mA

rated speed:9750rpm

rated torque:55mNm

rated current:3A

stall torque:400mNm

stall current:16A

max efficiency:82%

terminal resistance:1.5

terminal inductance:0.2mH

torque constant:18.3mNm/A

speed constant:475rpm/V

rotor inertia:50





Dimension drawing:



DC24V high speed motor





36mm coreless motor photo:



DC24V high speed motor

Benefits:

  1. Compact size (About 1/3 size and 1/3 weight of PMDC motor when compared with same power)
  2. Low inertia (For extremely fast acceleration and deceleration.
  3. High efficiency: (Low current consumption and low staring voltage)
  4. Reliability (Operates more quietly, longer services life and low inductance)

Features

  1. Precise long life motors
  2. High efficiency and high torque in a small package
  3. Sizes ranges from 16mm to 35mm diameter
  4. Output power is from 1.0 to 45 watts
  5. Double winding technology
  6. Gearheads, encoders, shafts modifications available
  7. Perfect for battery operated applications
  8. Excellent for use when space is a premium
  9. Size is 1/3 less when compared with an standard type brushed motor of same power

Applications

  1. Military Industry – Tracking aiming, missile system and automatic aiming machine
  2. Medical Equipment – X- ray, peristaltic pumps, and ophthalmic tools
  3. Instrumentation – Laser leveling devices, precision balances and gas analyzing device
  4. Security Equipment – Air sampling, camera platforms and electronic lock
  5. Office Equipment – Card readers, scanners and printers
  6. Machinery & Equipment – Robot, electric tools and miniature pumps

Production flow:





DC24V high speed motor



DC24V high speed motor



DC24V high speed motor





Since Dong Hui Motor established in 2003, has been committed to the development and production of micro motor, including 4 major product series: Micro DC motor, DC gear motor, coreless motor, brushless motor. All products are widely used in consumer electronics, electric toys, household appliances, home appliance,office automation equipment, medical equipment, power tools, automotive and other fields. Learn More About us:

1. Our main products: Dia4~100mm DC Micro Motor, Auto dc motor, Electric motor,Coreless Brushless motor, Gear Motor, DC Motor, Brush DC motor, Spur Gear motor, Micro Motor, Vibration motor etc.

2. Products size range: Diameter: 4-100mm

3. DC Voltage range: 1.5V -42V

   AC rectify: 100V, 110V, 220V, 230V, 240V etc.

4. Speed range: 1 RPM-30,000RPM

5. Stall torque: 1g.cm-30kg.cm

6. Application: Home appliance, Power Tools, Toys & Model, Precision Instrument, Office equipment, Personal care product, Automotive, Audio& Visual equipment etc.
