Supplier Program-control Hydraulic WD-670HP Hydraulic Paper Cutter
Design with CE standard,
Heavy-duty stander,double hydraulic drive system,
Oscillating oil cylinder technology,
optical line
WD-670HP Hydraulic Programing Paper Guillotine Hydraulic paper cutter
Design with CE standard, front grating safety protection and back protection cover conform to safe system
Heavy-duty stander, symmetrical pressing paper function and double hydraulic drive system
Inclined cutting technology
Spin cutter with adjusting depth curve technology device
Adjustable gap of blade carrier technology with patented
Oscillating oil cylinder technology
Double orbit push paper function for guarantee of precision
Programmed circuit design, being able to save 99 group data with setting program at will
Opitical Cutting Line
Fashionable appearance design with patented
| MODEL | WD-670HP |
| Max.Cutting Size | 670mm |
| Min. Cutting Size | 30mm |
| Max Cutting Thickness | 80mm |
| Cutting precision | :±0.3mm |
| Pressing Paper Mode | Hydraulic |
| Cutting Paper Mode | Hydraulic |
| Pushing Paper Mode | Digital control |
| Program | Yes |
| Display | Liquid Crystal Display LCD |
| Power Supply | AC220V(110V)±10%50HZ60HZ,2.35KW |
| Net Weight | 480kgs |
| Gross Weight | 520kgs |
| Machine Dimension(H*D*W) | 1290*1310*990mm |
