Excavator long reach
Negotiable
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- Shenzhen
- T/T
You May Like
-
Internal gear 40cr 41A0076 for Liugong loader parts ,axle parts
-
Liugong Wheel loader parts Liugong spare parts SP104817 Gland
-
Liugong Spare parts Castle nut 03B0050 Standard parts for Liugong Wheel loader parts
-
Conical roller bearing 23B0019 Standard parts for Liugong Wheel loader parts
-
Liugong spare parts flasher relay 31B0005 fpr Liugong Wheel loader parts
-
Air tank assembly ,pressure controller 13C0015 for Liugong Wheel loader parts
Product Description
Specifications
Excavator long reachWe take OEM order, good quality & price
Full package( bucket, cylinder, linkages, tubes.)
Excavator long reach
We provide complete package include
| 1 pcs x Boom |
| 1 pcs x Arm/stick |
| 1pcs x Bucket cylinder |
| 1pcs x Bucket, Grab or custom attachment |
| 1set x Bucket Linkages ( H Link, I Link) |
| 4pcs x Hoses, steel tubes etc. |
| 6pcs x Pins |
Application
| -Ideal for dredging river and sea either on land or on barge |
| -Basement and deep foundation excavation |
| -Construction of ditches,levees and ponds |
| -Construction of sea wall |
| -Dredging port,large range excavation and other purpose |
| -Demolishing high buildings and Structures |
Some parameter
| Common type | A | B | C | D | E | F | G |
| Total length (mm) | 13000 | 15380 | 1800 | 18000 | 20000 | 22000 | 24000 |
| Self weight (kg) | 3000 | 4000 | 4200 | 5200 | 6000 | 6500 | 7000 |
| Max dig dept (mm) | 9000 | 11340 | 12200 | 12200 | 14500 | 16100 | 18000 |
| Max extensive Scope (mm) | 12500 | 15100 | 17600 | 17600 | 19600 | 21600 | 23600 |
| Max dig height (mm) | 11300 | 12510 | 13500 | 13720 | 14920 | 16100 | 17300 |
| Folding height (mm) | 2900 | 2980 | 3040 | 3210 | 3210 | 3400 | 3400 |
| Bucket volume (m3) | 0.3 | 0.6 | 0.4 | 0.4 | 0.5 | 0.6 | 0.6 |
| Suitable excavator Tonnage(ton) | 12 | 20 | 20 | 30 | 35 | 35 | 45 |
Product & factory view
