high temperature kiln for ceramics / ceramic kiln / pottery kiln furnace
Brief introduction of the kiln for ceramics:
CY-M1200-L is designed with programmable controller with at Max. 30 steps. Heated by resistance wire, it can research the Max. temperature 1200C and the working temperature no more than 1100C. It is heated with 4 side and has the high accuaracy of 1 C.
It also can be designed with the selves, and it is a perfect heat treatment equipment for ceramics, pottery.
It also can be used as equipment for material or items heat treament in air atmosphere.
Specification of the high temperature kiln for ceramics , pottery.
| Model | CY-M1200-L |
| Chamber model | Side Door |
| Display | LED |
| Limiting temperature | 1200℃ |
| Working temperature | ≤1100℃ |
| Heating rate | Suggestion 0~20℃/min |
| Temperature accuracy | ±1℃ |
| Inside chamber size |
600*600*600mm ; other standard size we have: 500*500*500mm; 400*400*400mm; 350*350*350mm ;200×200×300(mm) The chamber size can be designed as your requirement! |
| Heating element | resistance wire |
| Thermal couple | K Type |
| Temperature control | PID automatic control via SCR power control |
| Heating curves | 30 steps programmable |
| Chamber material | Alumina Fiber |
| Rated power | 20 KW |
| Working voltage | AC 240-480V 50-60Hz |
| Warranty | 12 month (exclusive wearing part) |
Disply of the high temperature kiln for ceramics / high temperature oven furnace
wooden case
Zhengzhou CY Scientific Instrument Co., Ltd.- is a high and new technology enterprise registered in Zhengzhou,Henan province. Zhengzhou CY Scientific Instrument Co., Ltd is mainly engaged in researching and developing, designing and manufacturing of equipment used in scientific researches.
Our mainly products include high temperature furnace and heating element, like lab muffle furnace, tube furnace, dental furnace, vacuum furnace,gold melting furnace, SiC heating element, MoSi2 heating element, alumina tubes and crucibles, and etc.
contact information online:
contact person: Alisa Wang
skype: cykyfurnace
Mobile:+86 15515716046
