Wheel Farm Tractor

Wheel Farm Tractor thumbnail-1
Wheel Farm Tractor photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
2WD
Contact Supplier Request Quote Chat Now
Shenzhen Wishope Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 2WD
Usage Farm Tractor
Drive Type Gear Drive
Certificate CE
Brand Name WISHOPE
Model Number WSN-12
Place of Origin Zhejiang, China
After-sales Service Provided Engineers available to service machinery overseas



Product Description



Chassis Information

Model

WSN-12

Overall Dimensions:(L×W×H)

2950×980×1240mm

Wheel tread

570,630,690,750,810mm

Tires

Front 6.00-12

Rear 4.00-8

Skid Wheels

2 Nos. 42 Kg

Ground clearance

210mm

Working weight (with rotary tiller)

330 kg

Speed (km/hr)

Forward 1.41, 2.51, 4.21, 5.22, 9.27, 15.56

Reverse 1.11, 4.12

Rotary tiller

Model:1GL-60

Whole weight: 118 kg

Width 600 mm

Transmission type: chain drive

Turning Speed: 1st: Low:200, High:251; 2nd: Low:233, High:291

Number of blades: 18 pieces

Engine Information

Model

RV125-2, original Viet Nam VIKYNO model

Type

Single cylinder,4-stroke,horixontal,water-cooled,diesel

Bore x Stroke (mm)

90x94

Displacement (cm3)

624

Continuous output (HP/r.p.m)

10.5/2200

Maximum output

12.5/2400

Maximum torque (kgm/rpm)

4.04/1800

Compression ratio

18

Fuel

Light diesel oil

Fuel tank capacity (L)

9.5

Specific fuel consumption (g/HP/hr)

185

Nozzle opening pressure (kg/cm2)

220

Lubricating oil

SAE 30,20 10W-30

Lubricating oil system (L)

2.8

Combustion system

Direct Injection

Starting system

Handle Starting

Lamp

6V-25W

Cooling system

Condenser (Radiator)

Cooling water capacity (L)

2.1

Weight (kg)

105

Container Load

Qty/20' FCL

20 PCS(22 PCS/20FTC,mud wheels outside the packing)

Qty/40' FCL

40 PCS(48 PCS/40FTC,mud wheels outside the packing)
