High quality automatic car wash machine, car wash equipment
Features:
1. It is used for car, jeep, microbus and other small vans, with function of washing, waxing, drying, etc.
2.The complete structure is painted galvanized plate and square tube frame, avoiding corrosion and improving the corrosion resistance of the surface.
3. Internationally renowned brands of motor and reducer, security and stability, provide long life.
4. PLC controlled system, depending on different models to make process of washing solution.
5. With brush system, drying system, shampoo system and wax system.
6. The size change of machine is available on request.
Optional under chassis wash systems and water recycling system.
Technical Data (Standard):
Machine sizes (L x W x H): |
2100x3700x3000 mm |
Machine weight: |
2500KG |
Washable car sizes (L x W x H): |
5500x1950x2000 mm |
Rail Length: |
10000mm |
Width between rails: |
3245mm |
Conveyor speed: |
4.5-6 m/min |
Washing capacity: |
60-80 cars per hour |
Water consumption: |
100-120 liters per car |
Power supply & consumption: |
380V, 50Hz, 3 Phase, 19kw |
Compress air supply: |
5-8 bar |
Technical Data (Special Type):
Machine sizes (L x W x H): |
1800x3950x3100 mm |
Machine weight: |
3000KG |
Washable car sizes (L x W x H): |
6000x2350x2100 mm |
Rail Length: |
12000mm |
Width between rails: |
3500mm |
Conveyor speed: |
4.5-7m/min |
Washing capacity: |
60-80 cars per hour |
Water consumption: |
50-200 liters per car |
Power supply & consumption: |
380V, 50Hz, 3 Phase, 20kw |
Compress air supply: |
5 bar |
Picture of car wash machine installed at the service station:
Picture of pump:
Picture of control box-1:
Picture of control box-2:
Picture of horizontal blower with big power:
Test the machine before the shipment in the factory!!!
Ensure the quality of each product !!!!
Good packing in the container:
