Home > Industrial Equipment & Components > Ventilation Equipment > Blowers > Export Single Stage Centrifugal Blower

Export Single Stage Centrifugal Blower

Name: Export Single Stage Centrifugal Blower
Brand: ERAN
SKU: 112021495
Availability: InStock

Export Single Stage Centrifugal Blower thumbnail-1

Export Single Stage Centrifugal Blower thumbnail-2

Export Single Stage Centrifugal Blower photo-1

Export Single Stage Centrifugal Blower photo-2

US$ 250 - 850 MOQ: 1 Piece

Key Specifications

Get Latest Price

Electric Current Type:

Blade Material:

Other, Steel

Mounting:

Free Standing

Contact Supplier Request Quote Chat Now

Chongqing Eran HVAC Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Chongqing; Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Electric Current Type AC

Blade Material Other, Steel

Mounting Free Standing

Place of Origin Chongqing, China

Brand Name ERAN

Model Number HTFC-IB

Power 0.5-8.0

Voltage 380V

Air Volume 2000-45000

Speed 0-100

Certification CCC

After-sales Service Provided No overseas service provided

Cabinet Type Small Ventilatior with Centrifugal Fan Blower HTFC-IB

Product Description:

HTFC-1B centrifugal blower is a kind of cabinet type blower with high efficiency and low noise. According to different installation places, it can provide 12 kinds of in-outlet angle. Compared with Axial-flow type ventilator, the price is higher while it can provide better mute effect and it is more suitable for the places where demand low noise and special outlet angle.

Structure:

High quality galvanized steel sheet or color plate , strong corrosion-resisting
Advanced laser cutting machine, precision of burr-free blades are less than 0.3mm
Frame, box board assembly design
Galvanized noise elimination micro perforated panels and superfine glass wool to reduce the noise level.

Features:

Product is removable and conducive to transport, and convenient for field installation
In strict accordance with the standard for quality inspection and assessment of Ventilation and air-conditioning works(gbj304-88)
Dual frequency motor available

Standard Device:

Impeller, chassis ( chassis, collector , bracket ) ; motor ; bearing ( shell ) ; spindles ; pulleys , belt ; belt cover (A type only ) ; Motor regulator track ; flange

Optional accessories : damping device ; filter ; mating flanges ; muffler ; control box ; Motor rain tank ( only A -type )

Performance table

Model Sheet:

Device Number	Rotating Speed(r/min)	Air Volume(m³/h)	Total Pressure(Pa)	Motor Model	Power(kw)	Weight(kg)
10"	1600	4050	684	YDT100L2-4/6	2.2	121
		4530	673
		5100	665
	1066	2700	304		0.7
		3020	299
		3400	296
12"	1275	6457	714	YDT112M-4/6	3.2	167
		7293	711
		8129	707
	850	4305	317		1.1
		4862	316
		5419	314

The above table is just part of the performance of our product. We can provide customized product, so please make your performance requirements.

Application:

It is widelyused in hotel, assembly hall, theater, underground basement, industrial and mining enterprises, etc.Especially it apply to the places where need low noise and high volume of air.

Our company:

Eran was established in 2005, whose plant covering an area of over 10,000 square meters. We are a professional enterprise and specialized in ventilation system products design, manufacture, sale and installation.

There are 3 set of advanced production lines with numerical control, advanced shearing, bending and stamping equipment, and precision plasma cutting & vent processing machine. By using of the advanced BIM technology and assembly line operation, Eran Equipment’s technological level and production capacity has arrived at the leading position of this industry. The company has passed ISO9001 Quality Management System, ISO14001 Environmental Management System and GB/T28001 Occupation Health Safety Management System.

Our service:

Your inquiry and question will be replied within 24 hours.
Professional foreign sales staff gives you best service.
Our products include: ventilation fan, air duct, air valve, air vent, plenum chamber, muffler, soft connecter and accessories
All our products will be provided with best quotation, excellent quality and prompt delivery.
Sample is available by express.
OEM is available
