Low temperature circulator LX -25℃~30℃
Feature of low temperature circulator
1.Saving resources;
2.closed cycle pipeline design highly prevent circulating water pollution and extend the lifetime of circulation liquid.
Technical Parameters for low temperature circulator:
Model |
LX-0250N |
LX-0400N |
LX-0700N |
LX-1000N |
LX-1450N |
LX-2000N |
|
Medium Temperature Range |
-15℃~30℃ |
-25℃~30℃ |
-25℃~30℃ |
-25℃~30℃ |
-25℃~30℃ |
-25℃~30℃ |
|
Temp. control |
ASET multifunctional controller |
||||||
Temp. control optional |
Heat-conducting medium outlet temp. control |
||||||
communication protocol |
MODBUS RTU Protocol, RS 485 Interface |
||||||
Temp. feedback |
Heat-conducting medium temperature feedback PT100 |
||||||
Cooling capacity |
0℃ |
1.5kW |
2.4kW |
4kW |
7.5kW |
10kW |
15.5kW |
-10℃ |
1kW |
1.5kW |
2.7kW |
6.3kW |
8kW |
12kW |
|
-20℃ |
0.55kW |
0.8kW |
1.5kW |
3.5kW |
5kW |
7.3kW |
|
Circulation pump |
Max20L/min 0.7BAR |
Max20L/min 0.7BAR |
Max35L/min 1BAR |
Max50L/min 1BAR |
Max75L/min 1BAR |
Max75L/min 1BAR |
|
capacity of liquid storage |
15L |
25L |
30L |
35L |
45L |
60L |
|
Compressor |
Tecumseh |
Tecumseh |
Copeland |
Copeland |
Copeland |
Copeland |
|
Evaporator |
copper tube |
||||||
Operating controller |
7-inch color touch screen, temperature curve record, excel-format export |
||||||
Security protection |
Self-diagnosis function; freezer overload protection; high pressure switch; overload relay, thermal protection device etc. security protection function. |
||||||
Refrigerants |
R-404A |
||||||
Connection size |
DN-15 |
DN20 |
DN20 |
DN20 |
DN20 |
DN-20 |
|
Product size (air-cooled) |
400*600*1050 |
400*600*1150 |
500*680*1350 |
550*680*1450 |
620*680*1550 |
750*750*1750 |
|
Weight (air-cooled) |
115KG |
145kg |
180kg |
225kg |
290kg |
340kg |
|
Power |
AC220V 50HZ 1.5kW (max) |
AC220V 50HZ 2.2kW (max) |
AC220V50HZ 3.5kW (max) |
AC380V 50HZ 4kW (max) |
AC380V 50HZ 5kW (max) |
AC380V50HZ 6.5kW (max) |
|
Material |
Cold rolled steel |
||||||
Optional |
Match 7-inch color touch screen controller, temperature curve record, data export to excel format. |
||||||
Optional |
Circulation Pump Optional: 35L/min 2.5bar 50L/min 2.5bar 110L/min 2.5bar |
||||||
Optional |
SUS304 material |
||||||
Optional |
Pressure max. 10 bar circulating pump |
||||||
Optional Power |
220V 60HZ three-phases, 440V~480V 60HZ three-phases |
||||||
Remark |
Can make the bigger capacity of water storage as required. |
||||||
Photo of chiller
Packing of chiller
