CHEERLINK 1080P 2X6 60m HDMI Splitter / Switch / Extender w/ EU Plug - Black
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
CHEERILNK
Model Number:
HDES07
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CHEERLINK Full 3D Mini HDMI 1.4a Splitter 1 Input 2 Output- BlackNegotiableMOQ: 50 Pieces -
CHEERLINK 1in 2 Out Full HD/3D HDMI Amplifier Splitter Multiple DisplaysNegotiableMOQ: 100 Pieces
-
1 in 2 Out Hdmi Splitter Switch Support Full 2160P 1080P 3D v 1.3&V1.4 HDMI Splitter 1*2 w/ Remote Control - BlackNegotiableMOQ: 50 Pieces
-
2 Input Full HD/3D HDMI Amplifier Splitter Connects to Digital Video Source Such as DVD, Satellite, Cable Box, PC, PS3NegotiableMOQ: 100 Pieces
-
CHEERLINK New Product Uhd 2160P 4K2K HDMI Splitter 1x2 / Remote Control/blackNegotiableMOQ: 50 Pieces
Brand Name
CHEERILNK
Model Number
HDES07
Place of Origin
China
Product Description
This 2*6 HDMI Splitter/Extender over single Cat 5e/6 connect 2 HD signals sources with multiple HD display terminal, it can easily split any HD signals to more than one HDTV or projector which support HD. And it can extend HDMI signal up to 60m by one cat 5e / 6(need to be used with RX receiver).
| General | |
|---|---|
| Brand | CHEERLINK |
| Model | HDES07 |
| Material | Aluminum alloy + electronic components |
| Color | Black |
| Quantity | 1Piece |
| Other Features | |
| Cable Length | 118cm |
| Connector | Cat 6, Cat 5e , Cat 6 , Cat 5e , HDMI |
| Plug Specifications | EU Plug (2-Round-Pin Plug) |
| Power Supply | Input : AC 100V - 240V 50/60Hz 0.7A Max Output : 5V-3A |
| Other Features | - HDMI version : HDMI1.4a - HDMI Resolution : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i - Support video format: 8/10 bit deep color - Support audio format : DTS/HD/Dolby-trueHD/DTS/Dolby-AC3/DSD - HDMI input port: 2 - HDMI output port: 2 - RJ45 port: 4 - Maximum bandwidth: 225MHz - Maximum baud rate : 2.25Gbps - Input cable distance : < = 15 m AWG26 HDMI standard cable - Output Cable length: <=60m cat5e/cat6 or < = 25 m AWG26 -HDMI standard cable - Maximum Working Current : 1600mA - Operating temperature range : (-15 to 55 Celsius ) - Supports 3D - The signal transmission: it can be up to 60 meters between receiver and transmitter by using one cat 5e/6 instead of HDMI cable - Supports single and HD display for multiple sources, such as DVD players, A/V Receivers and set-top box for operational flexibility and easy to control - Two HDMI inputs can be interactive switched, it can be used as a HDMI switch 2*1 - Two HDMI outputs can be connected with TV directly, it can be used as a HDMI splitter 1*2 |
| Dimensions & Weight | |
|---|---|
| Dimensions | 8.35 in x 2.95 in x 0.87 in (21.2 cm x 7.5 cm x 2.2 cm) |
| Weight | 13.79 oz (391 g) |
| Packing List |
|---|
| 1 x HDMI Splitter / Extender 1 x IR Remote Control (1 x CR2025 battery, included) 1 x Power Adapter (2-round-pin plug Input: AC 100~240V 50/60Hz 0.7A Max Output: 5V-3A, 118cm) 1 x Chinese & English User Manual |
