Specifications
Rotation type Industrial pulverized coal burner1.New Desgin
2. Energy Saving
3.Long working Life
4.High Quality
Coal Burner Introduction
Scope of Application:
The coal burner made by our company is mainly used in asphalt plant, boiler, dryer (such as brick kiln), metallurgy and other industries.
Main Components:
1. Pulverized Coal Machine
2. Coal Burner (combustion chamber, automatic back and forth motion system
3. Automatic rotation system, the combustion air supply system)
4. Control system
5. Ignition system
6. The crater and others
Main parameter Table of Coal Burner
Type | Coal consumption(kg) | Total power (kw) | Diameter of fire(m) | Length of fire (m) |
MFR20 | 180-280 | 21.75 | 0.4 | 0.6-1 |
MFR40 | 370-560 | 32.75 | 0.7 | 1-1.7 |
MFR60 | 560-840 | 32.75 | 0.8 | 1.4-2 |
MFR80 | 720-1120 | 42.75 | 0.8 | 1.4-2 |
MFR120 | 1120-1680 | 67.75 | 1.1 | 1.6-2.7 |
MFR160 | 1490-2240 | 81.75 | 1.1 | 1.6-2.7 |
MFR200 | 1850-2800 | 106.75 | 1.2 | 1.8-3 |
MFR240 | 2240-3360 | 140.65 | 1.2 | 1.8-3 |
MFR320 | 2980-4480 | 197.15 | 1.3 | 2-3.2 |
MFR400 | 3730-5600 | 257.15 | 1.3 | 2-3.5 |
Pulverized Coal Machine
Model:FMJ20,FMJ40,FMJ80,FMJ120,FMJ150
The broken hammer is made by NM500 high wear-resisting material.
The screw conveyor is controlled by frequency converter for coal supplying.
The first-class accessories(motor, reducer, bearing etc). User can specify a brand.
The shell manufactured by super thick high strength steel plate, which avoid the body vibration effectively.
Coal Burner
It is composed of combustion chamber, automatic back and forth motion system, automatic rotation system, the combustion air supply system.
1. Coal Burner using the exclusive revolving burning chamber to solve traditional burning problems, such as relict agglomeration and burning incompletely
2. High flame temperature, more energy-saving.
3. Coal Burner is equipped with exclusive fire-brick, prolonging the service life
4. With simple and convenient ignite way; manual or automatic way is optional.
5. Coal Burner could work continuously, don’t need to clear clinker every day.
6. Compared with oil burner, coal burner costs lower.
7. The whole burner is could be automatically controlled.
Control System
PLC Touch Screen Control System
Our coal burner can be equipped with PLC touch screen control system. The whole control process visualization, the operation is simple and convenient. Meanwhile interface can use English, Russian, etc
Damper automatic adjustment—effectively reduce the coal consumption of burner
Automatic Temperature Control
According to the drying drum discharging temperature, real-time adjustment for coal supply
Ignition system
Automatic ignition device
Project Case
