Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Audio & Video Cable > CHEERLINK HDMI 1.3 Matrix 4x4 w/ IR Remote Control Hdmi Switcher / Splitter
CHEERLINK HDMI 1.3 Matrix 4x4 w/ IR Remote Control Hdmi Switcher / Splitter
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
CHEERLINK
Model Number:
DX348912
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CHEERLNIK HDMI True Matrix 4-in 2-out Full 1080p Supported 3D V1.3 HDMI Matrix 4*2 w/ Remote Control - BlackNegotiableMOQ: 50 Pieces -
CHEERLINK 4x4 Full HD 1080P HDMI V1.3 True Matrix RS232 w/ Remote Control - BlackNegotiableMOQ: 50 Pieces
-
CHEERLINK 4-In 2-Out Full HD 1080P HDMI True Matrix W/RS232 Control - BlackNegotiableMOQ: 100 Pieces
-
CHEERLINK 4-In 4-Out Full HD 1080P Support 3D True Matrix 4*4 w/ Remote Control - BlackUS$ 115.99 - 120MOQ: 100 Pieces
-
CHEERLINK 4 x 2 1080P High Fidelity HDMI Matrix SwitchUS$ 37.5 - 39MOQ: 500 Pieces
Brand Name
CHEERLINK
Model Number
DX348912
Place of Origin
Guangdong, China
Product Description
The 4 x 4 HDMI MATRIX can connect four HDMI signal sources with the four displays at the same time. It can easily and freely split or switch four HDMI signals on four displays or projectors which are compatible with HDMI signal. In addition, if connected its port with HDMI cable, it can amplify the HDMI signal. And it offers solutions for noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environment.
- HDMI version: HDMI1.4a
- HDCP version: 1.4
- Support audio color format: 12 bit
- Support audio format: DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD
- Maximum baud rate: 2.25Gbps
- Input/output TMDS signal: 0.5-1.5Vp-p
- Input/output DDC signal: 5Vp-p(TTL)
- Input cable distance: <=10 m AWG26 HDMI standard cable
- Output Cable length: <=15 m AWG26 HDMI standard cable
- Maximum Working Current: 1.3 A
- Operating temperature range: (-15~55'C )
- Operating humidity range: 5 to 90%RH (no condensation)
- Supports CEC
- Supports Blue-ray 24/50/60fs/HD-DVD/xvYCC
t
- Supports signal timing rese
- Supports AWG26 HDMI standard cable, input up to 15 meters, output up to 20 meters
- Input ports can be controlled by IR remote control
- Via RS-232 control, the machine can upgrade the software, and the input and the output can be switched by computer
- No signal loss
- HDMI version: HDMI1.4a
- HDCP version: 1.4
- Support audio color format: 12 bit
- Support audio format: DTS-HD / Dolby-trueHD / LPCM7.1 / DTS / Dolby-AC3 / DSD
- Maximum baud rate: 2.25Gbps
- Input/output TMDS signal: 0.5-1.5Vp-p
- Input/output DDC signal: 5Vp-p(TTL)
- Input cable distance: <=10 m AWG26 HDMI standard cable
- Output Cable length: <=15 m AWG26 HDMI standard cable
- Maximum Working Current: 1.3 A
- Operating temperature range: (-15~55'C )
- Operating humidity range: 5 to 90%RH (no condensation)
- Supports CEC
- Supports Blue-ray 24/50/60fs/HD-DVD/xvYCC
t
- Supports signal timing rese
- Supports AWG26 HDMI standard cable, input up to 15 meters, output up to 20 meters
- Input ports can be controlled by IR remote control
- Via RS-232 control, the machine can upgrade the software, and the input and the output can be switched by computer
- No signal loss
| General | |
|---|---|
| Brand | CHEERLINK |
| Model | N/A |
| Material | ABS |
| Color | Black |
| Quantity | 1Piece |
| Other Features | |
| Cable Length | 101cm |
| Connector | IR / RS232 / DC , HDMI |
| Plug Specifications | US Plug (2-Flat-Pin Plug) |
| Power Supply | Input: 100~240V /1A, 50 / 60Hz; Output: 12V /3A 101 cm |
| Certification | CE, FCC, RoHS |
| Dimensions & Weight | |
|---|---|
| Dimensions | 17.13 in x 7.09 in x 1.57 in (43.5 cm x 18 cm x 4 cm) |
| Weight | 65.43 oz (1855 g) |
| Packing List |
|---|
| 1 x Matrix 1 x Remote Control (2 x CR2025, included ) 7 x Screws 2 x Holder |
